SnoMaster 100309 71W Compressor Controller 12V

12 V DC Control Module for SnoMaster Compressor Systems

The SnoMaster 71W compressor controller is a 12 V DC control module for SnoMaster compressor-driven cooling systems. It manages compressor start-up, speed and protection circuits. The unit interfaces with the 71 W compressor used across several SnoMaster portable fridge and freezer models.

The controller accepts a 12 V DC input and regulates the compressor through a dedicated output stage. It monitors supply voltage and current draw to prevent deep battery discharge. A three-level cut-out threshold allows users to select the protection point that matches their battery bank.

The module mounts inside the compressor compartment and connects via standard spade terminals. It operates within a 0 °C to 50 °C ambient range and draws minimal standby current when the compressor is idle. The compact footprint fits the wiring harness used on SnoMaster low-profile and single-compartment cabinets.

Key Features

• 12 V DC Input
  The controller runs from a nominal 12 V DC supply and suits vehicle, caravan and solar-charged battery systems.

• 71 W Compressor Compatibility

  • Matches the SnoMaster 71 W compressor motor
  • Handles start-up inrush current without nuisance trips
  • Supports variable speed control where the compressor allows

• Voltage Cut-Out Protection
  Three selectable thresholds guard the supply battery against over-discharge during extended parked use.

• Spade Terminal Interface
  Standard spade connectors simplify wiring to the compressor, thermostat and power feed.

• Compact Module Housing
  The small enclosure fits inside the compressor compartment of portable fridge cabinets.

Specifications

What’s in the Box

• 1 x SnoMaster 100309 71 W compressor controller, 12 V

• Wiring instructions

Why Choose SnoMaster

• Direct replacement for the control module fitted to several SnoMaster 71 W cooling systems.

• The 12 V DC design matches common vehicle and caravan electrical architectures.

• Selectable cut-out thresholds let you balance runtime against battery reserve.

• Spade terminals reduce installation time during field repairs.

• Genuine service part preserves the original compressor protection logic.
