SC-LC OM3 Patch Cord 15m, Duplex 50/125µm UPC Multimode Fiber, LSZH Aqua
Limited Stock
SC-LC OM3 Patch Cord 15m, Duplex 50/125µm UPC Multimode Fiber, LSZH Aqua
| Connector A | SC/UPC male |
| Connector B | LC/UPC male |
| Fiber category | OM3 multimode, laser-optimized |
| Core / cladding | 50/125 µm |
| Fiber count | 2 (duplex zipcord) |
| Assembly length | 15 m |
| Insertion loss | 0.25 dB max per mated pair |
| Return loss | 30 dB min |
| Attenuation | 3.0 dB/km at 850 nm, 1.0 dB/km at 1300 nm |
| Jacket | LSZH, aqua |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Duplex Multimode Fiber Lead for 10G Short-Reach Links
The SC-LC OM3 15m links SC patch panels to LC transceiver ports across a duplex run. UPC-polished zirconia ferrules hold insertion loss at 0.25 dB or lower per mated pair. Aqua LSZH jacketing identifies the OM3 grade on sight.
Laser-optimized 50/125 µm fiber carries 850 nm and 1300 nm traffic. Maximum attenuation reaches 3.0 dB/km at 850 nm and 1.0 dB/km at 1300 nm. Overfilled launch bandwidth is 1500 MHz·km at 850 nm and 500 MHz·km at 1300 nm, so 10GBASE-SR runs reach 300 m.
The 2.0 mm zipcord splits into two 0.9 mm legs at each boot, which lets technicians set polarity. Minimum bend radius is 10 mm under load and 20 mm unloaded. Operating temperature spans -20°C to +70°C for indoor cabinets and equipment rooms.
Key Features
Hybrid SC to LC Termination
One end seats in an SC adapter panel while the other plugs into an LC SFP cage.OM3 Laser-Optimized Core
- 50/125 µm graded-index core with 2000 MHz·km effective modal bandwidth at 850 nm
- 10GBASE-SR reach to 300 m and 40GBASE-SR4 reach to 100 m
- Backward compatible with 1000BASE-SX and 100BASE-FX
UPC Ceramic Ferrules
Zirconia ferrules with ultra physical contact polish return 30 dB or better per mated pair.LSZH Aqua Jacket
Low smoke zero halogen compound limits toxic emissions in occupied rooms.Duplex Zipcord Construction
Two fibers share one outer jacket and split at the boots for A-B or A-A polarity.15 m Cross-Connect Span
The length reaches between adjacent cabinets or from a switch to a patch panel.
Specifications
| Feature | Specification |
|---|---|
| Connector A | SC/UPC male |
| Connector B | LC/UPC male |
| Fiber category | OM3 multimode, laser-optimized |
| Core / cladding | 50/125 µm |
| Fiber count | 2 (duplex zipcord) |
| Assembly length | 15 m |
| Insertion loss | 0.25 dB max per mated pair |
| Return loss | 30 dB min |
| Ferrule material | Zirconia ceramic |
| Polish | UPC |
| Wavelengths | 850 nm and 1300 nm |
| Attenuation at 850 nm | 3.0 dB/km max |
| Attenuation at 1300 nm | 1.0 dB/km max |
| Bandwidth at 850 nm | 1500 MHz·km min (OFL) |
| Bandwidth at 1300 nm | 500 MHz·km min (OFL) |
| Cable diameter | 2.0 mm |
| Jacket material | LSZH |
| Jacket colour | Aqua |
| Bend radius, loaded | 10 mm |
| Tensile strength | 70 N |
| Operating temperature | -20°C to +70°C |
| Storage temperature | -40°C to +85°C |
| Flame retardance | IEC 60332-1-2 |
| Standards | ANSI/TIA-568.3-D, ISO/IEC 11801, IEC 61755-3-1 |
| Applications | 10GBASE-SR, 1000BASE-SX, 40GBASE-SR4 |
What’s in the Box
15 m duplex SC/UPC to LC/UPC OM3 multimode assembly
Dust caps on all four connector ends
Insertion loss and return loss test label
Why Choose This OM3 Assembly
The hybrid connector pair removes the need for a separate adapter module between SC and LC patching fields.
Loss and return loss figures support link budget planning against ANSI/TIA-568.3-D channel limits.
Laser-optimized core leaves headroom for 10G upgrades on existing 1G multimode backbones.
LSZH jacketing meets indoor fire safety specifications for populated office floors.
Individual test labelling simplifies acceptance testing during commissioning.
