OM3 LC to LC UPC Duplex Multimode Patch Cord, 50/125 µm, 2.0 mm LSZH, Aqua
Limited Stock
OM3 LC to LC UPC Duplex Multimode Patch Cord, 50/125 µm, 2.0 mm LSZH, Aqua
| Connector type | LC/UPC to LC/UPC, duplex |
| Fiber category | OM3 multimode, 50/125 µm |
| Insertion loss | ≤0.3 dB per mated pair |
| Return loss | ≥35 dB (UPC) |
| Wavelengths | 850 nm, 1300 nm |
| Attenuation | ≤3.0 dB/km at 850 nm, ≤1.0 dB/km at 1300 nm |
| Cable diameter | 2.0 mm |
| Jacket | LSZH, aqua |
| Operating temperature | -20 °C to 70 °C |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Duplex Multimode Jumper for 10G and 40G Links
The OM3 LC patch cord terminates two 50/125 µm multimode fibers with LC/UPC plugs at both ends. The UPC polish holds return loss at 35 dB or better, and insertion loss stays at or below 0.3 dB per mated pair. Each assembly ships individually tested with a loss report.
A 2.0 mm zipcord jacket carries the fiber pair through high-density trays and 1U enclosures. OM3 glass supports 10G Ethernet to 300 m and 40G to 100 m at 850 nm. Attenuation holds at or below 3.0 dB/km at 850 nm and 1.0 dB/km at 1300 nm across the operating band.
Zirconia ceramic ferrules keep alignment stable through 1000 mating cycles. The LSZH sheath limits smoke and toxic fumes in enclosed rooms, and the aqua jacket identifies OM3 fiber at a glance. Loaded bend radius sits at 10 mm for tight cabinet routing, with operating temperature spanning -20 °C to 70 °C.
Key Features
LC/UPC Connectors at Both Ends
The 1.25 mm ferrule plugs mate with SFP, SFP+ and QSFP transceiver cages and LC adapters.Duplex Zipcord Construction
- Two fibers share one 2.0 mm jacket for TX/RX pairs
- Numbered connectors mark polarity without tracing
- Separates at the breakout for duplex adapter insertion
OM3 50/125 µm Glass
Laser-optimized fiber carries 10G to 300 m and 40G to 100 m at 850 nm.Low Insertion Loss
The connector pair holds insertion loss at ≤0.3 dB per IEC 61300-3-4 Method B.LSZH Aqua Jacket
Low-smoke zero-halogen compound suits enclosed cabinets and marks OM3 multimode fiber.Ceramic Ferrules
Zirconia ferrules hold alignment through 1000 mating cycles with ≤0.2 dB change.
Specifications
| Feature | Specification |
|---|---|
| Connector type | LC/UPC to LC/UPC, duplex |
| Polish type | UPC to UPC |
| Fiber category | OM3 multimode |
| Core / cladding | 50/125 µm |
| Fiber count | 2 (duplex zipcord) |
| Insertion loss | ≤0.3 dB per mated pair |
| Return loss | ≥35 dB (UPC) |
| Wavelengths | 850 nm, 1300 nm |
| Attenuation at 850 nm | ≤3.0 dB/km |
| Attenuation at 1300 nm | ≤1.0 dB/km |
| 10G reach | 300 m at 850 nm |
| 40G reach | 100 m at 850 nm |
| Cable diameter | 2.0 mm |
| Jacket material | LSZH |
| Jacket colour | Aqua |
| Ferrule material | Zirconia ceramic |
| Bend radius, loaded | 10 mm |
| Tensile strength, short term | 200 N |
| Mating durability | 1000 cycles, ≤0.2 dB change |
| Operating temperature | -20 °C to 70 °C |
| Storage temperature | -40 °C to 80 °C |
| Standards | IEC 61754-20, IEC 61300-3-4, TIA-568.3-D, RoHS |
| Application | 10GBASE-SR, 40GBASE-SR4, 100GBASE-SR10 |
What’s in the Box
Duplex LC/UPC to LC/UPC OM3 patch cord
Dust caps on both connector ends
Individual optical test report
Why Choose This Multimode Lead
Identical LC/UPC ends remove adapter dongles when patching switches to servers.
OM3 glass supports 300 m at 10G, covering most intra-building backbone runs.
LSZH jacketing meets enclosed-cabinet fire requirements without PVC smoke output.
Ceramic ferrules keep loss figures repeatable across repeated patching in test labs.
Aqua sheath lets technicians identify OM3 ports without reading labels.
