OEM OM3 Multimode SC-LC UPC Fiber Patch Cord
WhatsApp for availability
OEM OM3 Multimode SC-LC UPC Fiber Patch Cord
| Feature | Specification |
|---|---|
| Fiber Class | OM3 Multimode |
| Termination | SC to LC Duplex |
| Core/Cladding | 50/125µm |
| Jacket | LSZH Aqua |
| Distance | 300m @ 10Gbps |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
OM3 SC-LC UPC Fiber Cable
The OEM OM3 Patch Cord facilitates high-speed data transfer within 10 Gigabit Ethernet network environments. This duplex multimode fiber optic cable utilizes 50/125 micron laser-optimized glass. It maintains signal integrity over distances up to 300 meters. The assembly features one SC connector and one LC connector with Ultra Physical Contact polishing. This design accommodates high-density patching in modern data centers.
Key Features
Laser-Optimized 50/125µm Core
This specific fiber geometry supports 10 Gigabit Ethernet transmissions up to 300 meters at 850nm.Connector Architecture
- SC and LC connectors utilize high-quality ceramic ferrules for alignment.
- UPC polishing ensures a return loss of 30dB or better.
- Duplex clips maintain proper polarity for consistent signal flow.
Engineers utilize these optical jumpers to connect SFP+ transceivers and legacy hardware. The 2000 MHz·km effective modal bandwidth at 850 nm supports backbone applications. Each cable undergoes rigorous testing to ensure low insertion loss. The aqua-colored jacket signifies OM3 classification for quick identification. The LC connector utilizes a small form-factor design for increased port density. The SC connector provides a push-pull locking mechanism for secure connections. Ceramic ferrules inside the connectors maintain precise fiber alignment. This architecture withstands repeated mating cycles without performance loss.
Low Smoke Zero Halogen materials compose the outer jacket. This construction reduces toxic gas emissions during combustion. It meets safety standards for installation in enclosed areas. The 2.0mm jacket thickness provides flexibility for routing within management trays. Optical performance remains stable across a broad temperature range. This reliability ensures consistent uptime for critical business operations. The duplex configuration allows simultaneous bidirectional data flow. It eliminates the need for separate transmit and receive cables.
Standardized color coding simplifies troubleshooting and maintenance. The connectors feature strain relief boots to prevent damage from bending. This protects the delicate glass core from fractures. Professionals rely on these specifications for building scalable infrastructures. The core geometry measures 50 microns while the cladding stands at 125 microns. This ratio allows multiple modes of light to propagate. Laser-optimized multimode fiber specifically handles high-frequency VCSELs. These light sources offer a cost-effective alternative to single-mode lasers. Attenuation levels remain below 3.0 dB/km at 850 nm. This low signal loss enables longer link lengths. The UPC polish achieves a return loss of 30 dB. This reduces back-reflections that can interfere with laser stability.
Specifications
| Feature | Specification |
|---|---|
| Fiber Type | OM3 Multimode (50/125µm) |
| Connectors | SC to LC Duplex |
| Polish Type | UPC (Ultra Physical Contact) |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Bandwidth | 2000 MHz·km @ 850nm |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 30 dB |
| Max Data Rate | 10 Gbps (up to 300m) |
What’s in the Box
1 x Multimode SC-LC Fiber Assembly (OM3)
Individual Optical Test Report
Why Choose OM3 SC-LC UPC Fiber Cable
High-Speed 10G Support ensures compatibility with modern SFP+ transceivers.
Low Optical Attenuation maximizes signal strength across the network link.
LSZH Safety Compliance protects personnel and equipment in fire scenarios.
Customer Reviews
5 reviews for OEM OM3 Multimode SC-LC UPC Fiber Patch Cord
Clear filtersYou may also like
Ubiquiti UACC-OM-SM-10G-S-2 10G Single-Mode Optical Module
Price range: KSh 18,000.00 through KSh 150,000.00 ex VAT
Evans Mutua (verified owner) –
We were upgrading our server room links to 10G and these OM3 cords worked perfectly. The SC to LC transition is exactly what we needed for our older patch panels connecting to the newer SFP modules. No loss issues so far, very stable cables for the backbone.
Beatrice Njeri (verified owner) –
The build quality is decent for the price. Used them to link switches in our Westlands office. Delivery was fast, though I wish they had more length options in stock at the time. Still, it’s good value for money compared to what you find in downtown shops.
Kevin Omondi (verified owner) –
Sawa kabisa. These patch cords are reliable. The UPC connectors click in securely, no loose fittings like some cheap ones I’ve seen. Highly recommended for any local networking setup where you need that aqua OM3 speed.
Fatma Hassan (verified owner) –
Excellent fiber cables, zero issues with the signal throughput.
Samuel G. (verified owner) –
The cables work well for OM3 specs, but the plastic clips on the LC side feel a bit thin if you are handling them daily. You have to be careful when unplugging. Otherwise, the data performance is fine for our 10Gbps link.
