SnoMaster SMDZ-TR42 42L Single Compartment Mobile Fridge Freezer

Dual-voltage cooling for vehicles and camps

The SnoMaster SMDZ-TR42 is a 42-litre single-compartment mobile cabinet that runs from a 230 V AC wall socket or a 12/24 V DC vehicle supply. A 45 W compressor drives the refrigerant circuit across a -22 °C to 10 °C setpoint range. The cabinet ships in a white powder-coated finish with 50 mm polyurethane insulation.

Unit dimensions reach 520 mm high, 365 mm wide and 680 mm deep, measured with hinges, locks and handles fitted. Net weight is 23.5 kg and the packaged carton measures 560 x 425 x 710 mm. Rated current is 3.75 A at 12 V and 0.42 A at 220 V, so a modest auxiliary battery carries the load.

Three speed settings labelled High, Auto and Low trade pull-down speed against current draw. A selectable low-voltage cut-out at 10 V, 10.7 V or 11.8 V guards the starter battery on long unattended stops. Mini Anderson input and output plugs sit on the cabinet side.

Corner feet carry through-holes for bolting the unit to a load bed or trailer floor. Stainless steel hinges, locks and handles resist corrosion on coastal routes. An internal LED lamp and a lid-open alarm cover night handling, and the manual specifies 150 mm clearance on all sides.

Key Features

• 45 W compressor circuit
  The compressor holds setpoint instead of cycling a thermoelectric plate, which keeps contents stable in high ambient heat.

• Dual supply input

  • 230 V / 50 Hz AC operation from any standard socket
  • 12 V and 24 V DC operation from a vehicle harness
  • Mini Anderson plugs for input and output connections

• Three-speed compressor control
  High, Auto and Low modes let crews choose between fast pull-down and lower average current.

• Selectable low-voltage protection
  Cut-out thresholds of 10 V, 10.7 V and 11.8 V match different battery chemistries and vehicle wiring lengths.

• 50 mm polyurethane insulation
  The wall thickness slows heat ingress and reduces compressor run time in direct sun.

• Mounting and handling hardware

  • Corner feet with through-holes for fixed installation
  • Stainless steel hinges, locks and side handles
  • Moulded bottle opener on the body

• Interior lighting and alarm
  An LED lamp lights the compartment and a lid-open alarm warns when the lid stays unlatched.

Specifications

What’s in the Box

• 42-litre cooling cabinet

• Removable wire basket

• Bottle opener

• Transit cover

• Printed user manual

Why Choose the TR42

• One cabinet covers camping trips, delivery routes and load-shedding backup without a second appliance.

• The 42L portable fridge fits behind a double-cab bench and still holds a weekend of cold stock.

• Compressor cooling keeps the interior stable when ambient temperatures climb past 35 °C.

• Dual voltage input removes the need for a separate inverter in mixed 12 V and 24 V fleets.

• Through-holes in the feet allow permanent fixing to trailer and load-bed floors.

• Stainless steel hardware and a powder-coated shell tolerate dust, gravel and coastal air.
