SnoMaster 100194 70W Compressor 12/24V Without Controller
Original price was: KSh 72,600.00.KSh 55,400.00Current price is: KSh 55,400.00. ex VAT
SnoMaster 100194 70W Compressor 12/24V Without Controller
| Part number | 100194 |
| Compressor power | 70 W |
| Voltage | 12 V / 24 V DC |
| Refrigerant | R134a |
| Rated current | 5.92 A at 12 V, 0.52 A at 220 V |
| Controller | Not included |
| Mounting | BD35F compatible |
| Application | Portable fridge/freezer repair |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Replacement Cooling Unit for Portable Fridge Freezers
The SnoMaster 70W compressor is a bare replacement cooling unit for SnoMaster portable fridge/freezers. It ships without the electronic controller, so you reuse the existing module or fit a new one. The 70 W rating matches the compressor used across the SnoMaster low-profile and single-compartment ranges.
The unit runs on 12 V or 24 V DC and uses R134a refrigerant. It shares mounting dimensions with the Secop BD35F footprint, which simplifies drop-in replacement on older cabinets. A 5.92 A draw at 12 V and 0.52 A at 220 V aligns with the published ratings for SnoMaster 70 W systems.
Installation requires a qualified technician to recover and recharge refrigerant. The compressor arrives dry, so you must add the correct oil and gas charge during assembly. Use it with the SnoMaster interchangeable controller or a compatible aftermarket module rated for the same current.
Key Features
70 W Cooling Capacity
The 70 W motor drives the piston assembly used in SnoMaster 66 L to 80 L portable cabinets.Dual DC Voltage
- 12 V DC nominal for vehicle and caravan supplies
- 24 V DC nominal for truck and heavy-duty electrical systems
R134a Refrigerant
The compressor is rated for R134a, the standard gas in SnoMaster portable fridge circuits.BD35F Mounting Pattern
Mounting holes and foot dimensions match the Secop BD35F envelope for straightforward swaps.Bare Unit, No Controller
The package excludes the electronic control module, so you specify the controller separately.Service Part
This is a repair component intended for technicians handling sealed refrigeration systems.
Specifications
| Feature | Specification |
|---|---|
| Part number | 100194 |
| Compressor power | 70 W |
| Voltage | 12 V / 24 V DC |
| Refrigerant | R134a |
| Rated current | 5.92 A at 12 V, 0.52 A at 220 V |
| Controller | Not included |
| Mounting standard | BD35F compatible |
| Application | Portable fridge/freezer repair |
| Warranty | Contact supplier for terms |
What’s in the Box
1 x SnoMaster 70 W compressor, bare unit
Mounting hardware set
Why Choose SnoMaster
Direct replacement for the compressor fitted to many SnoMaster low-profile and single-compartment models.
BD35F-compatible footprint cuts adaptation time during repair.
12 V and 24 V DC input covers both light vehicle and heavy truck installations.
R134a refrigerant keeps the system within the original design parameters.
Genuine service part maintains the cooling performance of the original assembly.
