Temperature Controller Single Zone L2.7C CM40/60
Original price was: KSh 7,300.00.KSh 5,500.00Current price is: KSh 5,500.00. ex VAT
Temperature Controller Single Zone L2.7C CM40/60
| Model | L2.7C CM40/60 |
| Control type | PID with auto-tune |
| Input types | RTD Pt100, thermocouple J/K, 4–20 mA, 0–10 V |
| Output | SPDT relay, 5 A at 250 VAC |
| Supply voltage | 100–240 VAC, 50/60 Hz |
| Panel cutout | 45 x 45 mm (1/16 DIN) |
| Dimensions | 48 x 48 x 110 mm |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Panel-Mount Thermal Regulation for Single-Zone Processes
The temperature controller single zone is a panel-mount unit for closed-loop thermal regulation. Model L2.7C CM40/60 targets single-zone processes in refrigeration, ovens and incubators. It accepts common sensor inputs and drives a relay output.
The controller uses a PID algorithm with auto-tuning to hold setpoint stability. Front-panel keys configure setpoint, alarm limits and hysteresis without a PC. A dual 4-digit display shows process value and setpoint simultaneously.
Supply voltage covers 100–240 VAC for global panel supplies. The 1/16 DIN housing fits standard cutouts and saves panel space. Screw terminals accept wire up to 2.5 mm².
Key Features
Single-Zone PID Control
The PID loop with auto-tune adjusts output to minimise overshoot on start-up.Universal Sensor Input
- Accepts RTD Pt100, thermocouple types J and K
- Handles linear 4–20 mA and 0–10 V signals
- Cold-junction compensation built in
Relay Output
A SPDT relay rated 5 A at 250 VAC switches heaters, compressors or solenoids directly.Dual Display
Two 4-digit LED displays show process value and setpoint at the same time.Panel-Mount Housing
The 1/16 DIN case locks into a 45 x 45 mm cutout with rear retaining clips.
Specifications
| Feature | Specification |
|---|---|
| Model | L2.7C CM40/60 |
| Control type | PID with auto-tune |
| Input types | RTD Pt100, thermocouple J/K, 4–20 mA, 0–10 V |
| Output | SPDT relay, 5 A at 250 VAC |
| Supply voltage | 100–240 VAC, 50/60 Hz |
| Display | Dual 4-digit LED |
| Panel cutout | 45 x 45 mm (1/16 DIN) |
| Terminals | Screw, 2.5 mm² max |
| Operating temperature | 0 to 50 °C |
| Dimensions | 48 x 48 x 110 mm |
| Weight | 150 g |
What’s in the Box
1 x L2.7C CM40/60 single-zone temperature controller
2 x mounting clips
1 x instruction sheet
Why Choose This Controller
The panel mount thermostat format saves DIN rail space in dense cabinets.
Auto-tune shortens commissioning time on new oven or chiller installations.
Universal input covers the common sensor types found in refrigeration and process heating.
A relay output interfaces directly with contactors and solenoid valves without extra hardware.
Dual display allows operators to read setpoint and actual value without scrolling menus.
