12 Volt DC Cable – 5.5 x 2.1 mm Barrel Plug Power Lead, 1.8 m
Original price was: KSh 6,400.00.KSh 5,500.00Current price is: KSh 5,500.00. ex VAT
12 Volt DC Cable – 5.5 x 2.1 mm Barrel Plug Power Lead, 1.8 m
| Cable type | 12 V DC power lead |
| Conductor | Stranded copper, 18 AWG |
| Connector A | 5.5 x 2.1 mm barrel plug, male |
| Connector B | Bare tinned leads |
| Polarity | Centre positive |
| Maximum current | 5 A |
| Length | 1.8 m |
| Outer diameter | 4.5 mm |
| Voltage rating | 300 V |
| Temperature rating | 80 °C |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Low-Voltage Power Lead for 12 V Equipment
The 12 volt DC cable carries low-voltage power from an adapter or supply rail to a device that expects a 12 V input. It terminates in a 5.5 x 2.1 mm barrel plug with a centre-positive pin. Moulded strain relief protects the conductor joint where the lead enters the plug body.
Stranded copper conductors hold resistance low across the 1.8 m run. The 18 AWG gauge carries up to 5 A at 12 V DC, which covers routers, cameras, switches and small monitors. A flexible PVC jacket survives repeated coiling without cracking at the bend points.
The assembly suits bench testing, CCTV installation and field replacement of a lost lead. The barrel plug mates with the common 5.5 mm socket found on most 12 V devices. The cable rates 300 V and 80 °C, and the 4.5 mm outer diameter fits standard cable glands and trunking.
Key Features
18 AWG Stranded Copper
Stranded copper conductors keep voltage drop low over the 1.8 m run at 5 A.5.5 x 2.1 mm Barrel Plug
The moulded plug fits the standard 5.5 mm DC socket used on most 12 V hardware.Centre-Positive Wiring
The inner pin carries positive potential, matching the common polarity convention for DC adapters.Mechanical Construction
- Moulded strain relief at both ends
- Flexible PVC jacket, 4.5 mm outer diameter
- Rated 300 V and 80 °C
- Nickel-plated contacts resist surface oxidation
Flexible Jacket
The PVC sheath tolerates repeated coiling and tight radius bends in equipment racks.Field Serviceable Length
The 1.8 m span reaches from a power strip to a shelf-mounted device without excess slack.
Specifications
| Feature | Specification |
|---|---|
| Cable type | 12 V DC power lead |
| Conductor | Stranded copper, 18 AWG |
| Conductor count | 2 (positive and return) |
| Connector A | 5.5 x 2.1 mm barrel plug, male |
| Connector B | Bare tinned leads |
| Polarity | Centre positive |
| Rated voltage | 12 V DC |
| Maximum current | 5 A |
| Length | 1.8 m |
| Jacket material | PVC |
| Outer diameter | 4.5 mm |
| Voltage rating | 300 V |
| Temperature rating | 80 °C |
| Contact plating | Nickel |
| Colour | Black |
What’s in the Box
12 V DC power lead, 1.8 m
Why Choose This DC Lead
Stranded copper keeps resistive loss low on long shelf runs at 5 A.
The standard barrel plug fits the majority of 12 V routers, cameras and switches.
Moulded strain relief reduces conductor fatigue at the plug entry point.
Tinned bare ends accept screw terminals and lever connectors without extra ferrules.
The 300 V and 80 °C ratings cover indoor cabinet and trunking installation.
Centre-positive wiring matches the polarity of most DC power adapters.
