88218 7 Pin Plug Male Trailer Connector

Automotive Trailer Connector

The 7 Pin Plug Male is a 12 V trailer connector that follows the ISO 1724 Type N contact layout for towing vehicle wiring. It uses a moulded plastic body and screw terminals for field assembly. The male pins engage a matching female socket on the trailer harness.

Seven pins carry stop, tail, indicator, reverse, and auxiliary circuits. The plug accepts cable cores up to 1.5 mm² and secures each conductor with a screw clamp. A strain-relief gland holds the cable jacket and limits movement at the terminals. The contact block separates adjacent pins with moulded barriers.

The connector suits light commercial vehicles, caravans, and utility trailers with 12 V electrical systems. Installers strip the cable, terminate each core to the numbered pin, and tighten the housing. The plastic shell resists road splash and dust during normal towing duty. A rear compression gland accepts cable diameters from 6 mm to 8 mm.

Pin 3 carries the common return on a 2.5 mm² conductor, while the remaining six pins use 1.5 mm² cores. The plug rated current reaches 20 A on 1.5 mm² cable and up to 25 A on 2.5 mm² cable. Terminal screws use a pozidriv head and remain accessible after the housing opens. The black housing distinguishes the Type N plug from white supplementary Type S connectors.

The moulded body meets IP54 splash protection when the housing closes fully. Contacts use nickel-plated brass for corrosion resistance in humid or coastal conditions. The plug measures 72 mm in diameter and fits standard ISO 1724 socket shrouds. A removable rear cover exposes all seven terminals for inspection or re-termination.

Key Features

• Seven-pin male configuration
  Matches standard ISO 1724 female sockets on trailer harnesses.

• 12 V electrical rating
  Designed for nominal 12 V towing circuits in light vehicle applications.

• Screw terminal assembly
  Each pin accepts a stripped cable core and tightens with a screw clamp.

• Moulded plastic housing
  The insulated body separates the pins and protects the terminal block.

• Strain-relief cable entry
  A rear gland grips the cable jacket and reduces terminal stress.

• Numbered pin identification
  Terminal markings simplify wiring to the vehicle harness.

• Field-serviceable design
  The housing opens for inspection, re-termination, or pin replacement.

• ISO 1724 contact allocation

  • Pin 1 left indicator on 1.5 mm² yellow core
  • Pin 3 common return on 2.5 mm² white core
  • Pin 6 brake lights on 1.5 mm² red core

• IP54 splash protection
  The closed housing blocks dust and water spray during road use.

• Nickel-plated brass contacts
  Plated pins resist corrosion in humid and coastal operating conditions.

Specifications

What’s in the Box

• 88218 7-pin male trailer plug

Why Choose This Trailer Plug

• The ISO 1724 layout matches common towing sockets and reduces adapter requirements.

• Screw terminals allow installers to shorten or replace cable without special crimp tools.

• The plastic body insulates the pins and resists corrosion in road-splash environments.

• Numbered terminals and a removable housing simplify wiring checks and fault finding.

• Nickel-plated contacts and IP54 sealing support dependable service on light trailers.
