Outdoor OS2 Fiber Cable 4 Core Single Mode Per Meter

Singlemode Outside Plant Cable

The outdoor OS2 fiber cable carries four single-mode fibres in a loose-tube construction for outside plant runs. Each fibre uses a 9/125 µm core and cladding geometry with G.652.D low-water-peak performance. The cable ships cut to length and metre-marked for installation records.

A gel-filled central tube blocks water ingress along the cable core. Non-metallic strength members carry tensile load, and a UV-stabilised black outer jacket protects the assembly from sunlight and abrasion. The all-dielectric design removes the need for bonding and grounding at splice closures.

Typical attenuation reaches 0.35 dB/km at 1310 nm and 0.25 dB/km at 1550 nm. The cable handles duct, conduit and aerial lashed installation. Bend radius and tensile ratings support pulls through standard outside plant routes.

Key Features

• Four OS2 Singlemode Fibres
  The cable carries four 9/125 µm fibres compliant with ITU-T G.652.D and TIA-492CAAB OS2 requirements.

• Loose Tube Construction
  A gel-filled central tube isolates the fibres from mechanical stress and blocks longitudinal water migration.

• Outdoor Jacket

  • UV-stabilised black polyethylene outer sheath
  • Non-metallic strength members for tensile load
  • All-dielectric build, no bonding required

• Metre Marking
  The jacket carries sequential metre markings so installers can log splice points and route lengths.

• Low Attenuation
  Maximum attenuation measures 0.35 dB/km at 1310 nm and 0.25 dB/km at 1550 nm across the operating band.

• Cut to Length
  The cable sells per metre and supports exact route lengths without surplus reel inventory.

• Duct and Aerial Use
  The jacket and strength members suit conduit pulls and lashed aerial spans on outside plant routes.

Specifications

What’s in the Box

• 4-core singlemode cable, cut to ordered length

• Length and attenuation record label

Why Choose This Singlemode Cable

• The 4-core count covers duplex links with spare fibres for future splits.

• G.652.D fibre supports CWDM and DWDM overlays across the 1260–1625 nm range.

• Gel-filled loose tube construction resists water ingress in buried and ducted routes.

• All-dielectric materials simplify bonding and grounding at closures.

• Metre marking speeds up fault location and as-built documentation.

• Per-metre ordering removes the need to buy and store full reels.
