Nexa GYXTW 4 Core G652D Single Mode Fiber Cable
WhatsApp for availability
Nexa GYXTW 4 Core G652D Single Mode Fiber Cable
| Feature | Detail |
|---|---|
| Fiber Count | 4 Cores |
| Type | Single Mode G.652D |
| Armor | Corrugated Steel Tape |
| Strength | Parallel Steel Wires |
| Jacket | HDPE (Outdoor Rated) |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Nexa GYXTW 4-Core Cable
The Nexa GYXTW Fiber Cable provides a high-performance solution for outdoor data transmission in telecommunication and campus networks. This 4-core G.652D single-mode medium incorporates a central loose tube design to protect the glass fibers from environmental stress. The internal structure utilizes a water-blocking jelly to prevent moisture ingress and maintain signal integrity over long distances. Two parallel steel wires embedded in the jacket provide the necessary tensile strength for aerial and duct installations. A corrugated steel tape armor layer ensures physical protection against mechanical crush forces and rodent interference. The high-density polyethylene (HDPE) outer sheath offers resistance to ultraviolet radiation and temperature fluctuations in harsh climates.
Key Features
Uni-Tube Construction
The central loose tube contains four color-coded fibers immersed in a specialized water-repellent gel for maximum protection.Mechanical Reinforcement
- Dual parallel steel wires maintain cable stability during high-tension installation.
- Corrugated steel tape (CST) provides a 360-degree moisture barrier and superior crush resistance.
G.652D Fiber Standard
Low attenuation levels at 1310nm and 1550nm wavelengths ensure compatibility with standard long-haul networking equipment.Environmental Durability
The black HDPE jacket withstands extreme outdoor conditions and prevents degradation from direct sunlight exposure.
Specifications
| Feature | Specification |
|---|---|
| Fiber Count | 4 Cores |
| Fiber Type | Single Mode G.652D |
| Armor Type | Corrugated Steel Tape (CST) |
| Strength Member | Two Parallel Steel Wires |
| Outer Sheath | PE (High-Density Polyethylene) |
| Cable Diameter | 8.0mm ± 0.5mm |
| Tensile Strength | 1500N (Short Term) / 600N (Long Term) |
| Crush Resistance | 1000N / 100mm |
| Operating Temp | -40°C to +70°C |
What’s in the Box
Nexa GYXTW 4-Core G.652D Fiber Optic Cable (per meter/drum)
Technical Compliance Datasheet
Why Choose Nexa GYXTW 4-Core Cable
The armored design prevents downtime caused by rodent damage or accidental physical impact in underground ducts.
Dual steel wires allow for reliable aerial spans between poles without excessive sagging or fiber strain.
Low-dispersion G.652D glass supports high-bandwidth data transmission over distances exceeding 10 kilometers without repeaters.
The compact uni-tube profile simplifies installation in tight conduits where space is limited for traditional multi-tube cables.
Advanced water-blocking technology protects the optical core from moisture-related signal degradation in high-humidity environments.
Josphat Mwangi (verified owner) –
Good quality fiber for the price. We used this Nexa GYXTW for a small CCTV setup in Ruiru and the G652D cores are performing well. The outer jacket is tough enough for outdoor piping.
Faith Chebet (verified owner) –
Picked up a roll of this 4-core single mode for a client’s office link in Westlands. Very impressed with the build; the central loose tube design makes it easy to work with during termination. Splicing was smooth and the signal loss is minimal. Delivery to our site was also very fast. Highly recommend if you want something reliable that won’t break the budget.
