Front Runner BBRA002 Universal 105A Battery Bracket – Black Powder-Coated Steel

Universal Battery Mounting Bracket

The Front Runner battery bracket is a bolt-in mounting cradle for 105Ah deep-cycle batteries. It uses black powder-coated high-strength steel. All fitment parts ship in the carton.

The bracket accepts batteries up to 330 mm long, 175 mm wide and 240 mm high. Its own footprint measures 330 mm by 370 mm with an 80 mm depth. The assembly weighs 1.8 kg. Pre-drilled holes take standard bolts through a vehicle floor, canopy tray or drawer system base.

Front Runner builds the bracket from laser-cut and bent steel, then powder-coats it black. The coating resists scuffs and corrosion in engine bays and load bins. A formed lip traps the battery base and stops lateral movement on corrugated tracks.

Installation needs a drill, a spanner set and a torque wrench. Mark the hole positions on a flat surface, drill pilot holes and bolt the bracket down. Fit the battery, then tighten the retaining hardware to the battery manufacturer’s torque figure. Check the fasteners after the first rough section.

The universal hole pattern suits most 105Ah deep-cycle batteries from common brands. Front Runner lists the maximum envelope at 330 x 175 x 240 mm. Larger batteries need a different bracket. Check the battery datasheet before ordering.

The low 80 mm depth keeps the battery close to the mounting surface. That helps in canopies and drawer systems where headroom is limited. The bracket also works under a bonnet where the original tray has been removed. Confirm clearance to the bonnet before fitment.

Key Features

• 105Ah Battery Fitment
  The cradle holds a 105Ah deep-cycle battery up to 330 x 175 x 240 mm.

• Black Powder-Coated Steel
  High-strength steel with a black powder coat resists scuffs and corrosion.

• Pre-Drilled Mounting Holes
  The base pattern takes standard bolts through floors, trays and drawer bases.

• Complete Fitment Kit

  • All mounting hardware ships in the carton
  • Retaining bracket secures the battery base
  • No extra brackets required for the listed envelope

• Low 80 mm Profile
  The shallow body fits under canopies and inside drawer systems with limited headroom.

• Laser-Cut and Bent Construction
  Front Runner cuts and bends the steel in-house before powder coating.

Specifications

What’s in the Box

• Universal battery bracket

• Fitment hardware pack

• Installation instructions

Why Choose This Battery Mount

• The steel cradle stops battery movement on rough tracks and gravel roads.

• The 80 mm depth suits shallow canopies and drawer system bases.

• The powder coat resists corrosion in engine bays and exposed load bins.

• All fitment parts ship together, so installation needs no extra brackets.

• One bracket covers common 105Ah deep-cycle battery sizes.
