48-Port SC/UPC Duplex Multimode Fiber Panel – OM3 Pigtails, 1U 19-Inch Rack
Limited Stock
48-Port SC/UPC Duplex Multimode Fiber Panel – OM3 Pigtails, 1U 19-Inch Rack
| Fibre capacity | 48 fibres |
| Adapter type | SC duplex, UPC polish |
| Adapters | 24 duplex couplers |
| Pigtails | 48x OM3 SC/UPC, 900 µm buffer, 1 m |
| Attenuation | 3.0 dB/km at 850 nm, 1.0 dB/km at 1300 nm |
| Insertion loss | 0.3 dB maximum |
| Rack size | 1U, 19 inch (483 mm) |
| Depth | 200 mm |
| Housing | Aluminium, black |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Loaded 48-Fiber Multimode Housing
The 48 port SC/UPC duplex panel arrives pre-terminated with 24 duplex adapters and 48 OM3 pigtails. It occupies one rack unit in a 19-inch frame and accepts fusion splices inside the drawer. Technicians install it as a complete termination point rather than building one on site.
Each adapter carries two SC/UPC ceramic ferrules. OM3 fibre uses a 50 µm core with a 125 µm cladding and a 900 µm buffer. Attenuation runs at or below 3.0 dB/km at 850 nm and 1.0 dB/km at 1300 nm. Effective modal bandwidth reaches 2000 MHz·km.
The loaded drawer measures 483 x 44 x 200 mm and slides forward on steel rails. Two catches lock the tray at 45° for splicing and at 10° for routine inspection. The rear accepts four 10 mm gland entries plus two 20 mm ports, and an open centre section passes pre-terminated trunks.
Twelve-fibre groups follow the standard aqua OM3 colour code. Ports carry individual numbers above and below the adapter block for traceability. The aluminium housing ships with rack snap fixings and adjustable mounting ears.
Key Features
Pre-Loaded 24 Duplex Adapters
The front plate carries 24 SC duplex couplers that present 48 fibre ports without field assembly.48 OM3 Pigtails Terminated
Each pigtail ends in an SC/UPC connector with a ceramic ferrule and a maximum insertion loss of 0.3 dB.Sliding Splice Drawer
- Extends fully and tilts to 45 degrees for fusion work
- Locks at 10 degrees as a working platform
- Two catches release the tray without tools
- Adjustable ears set the panel depth inside the rack
OM3 Optical Performance
The 50/125 µm fibre supports 10GBASE-SR links to 300 m and 40/100G links to 100 m.Multiple Cable Entries
Four 10 mm gland holes and two 20 mm ports accept trunk cable and breakout tubing at the rear.Cable Management Inside the Tray
Securing points and routing holes hold fibre management coils in place during drawer movement.Numbered Fibre Ports
Printed port numbers above and below the adapter block speed up patching and fault tracing.Aluminium 1U Housing
The metal enclosure measures 483 x 44 x 200 mm and mounts on standard 19-inch rails.
Specifications
| Feature | Specification |
|---|---|
| Fibre capacity | 48 fibres |
| Adapter type | SC duplex, UPC polish |
| Adapter quantity | 24 duplex couplers |
| Pigtail connectors | SC/UPC, ceramic ferrule |
| Pigtail fibre type | OM3 multimode, 50/125 µm |
| Pigtail buffer | 900 µm tight-buffered |
| Pigtail length | 1 m |
| Attenuation at 850 nm | 3.0 dB/km maximum |
| Attenuation at 1300 nm | 1.0 dB/km maximum |
| Effective modal bandwidth | 2000 MHz·km at 850 nm |
| Overfilled launch bandwidth | 1500 MHz·km at 850 nm |
| Insertion loss | 0.3 dB maximum per mated pair |
| Return loss | 35 dB minimum, UPC multimode |
| 10GBASE-SR reach | 300 m |
| 40/100G reach | 100 m |
| Rack height | 1U (44 mm) |
| Rack width | 19 inches (483 mm) |
| Depth | 200 mm |
| Housing material | Aluminium |
| Colour | Black |
| Cable entries | 4x 10 mm glands, 2x 20 mm ports |
| Operating temperature | -10°C to 60°C |
| Storage temperature | -10°C to 60°C |
| Compliance | RoHS 2011/65/EU |
| Mounting | 19-inch rack, adjustable ears |
What’s in the Box
Loaded 1U fiber housing
24 SC duplex adapters fitted
48 OM3 SC/UPC pigtails
Splice trays and covers
Rack snap mounting fixings
Why Choose This Housing
Fusion splicing to pre-terminated leads removes field connector polishing from the build schedule.
OM3 bandwidth covers 10G links across a building floor and keeps 40G as a future path.
The sliding drawer gives splice access without pulling the housing out of the rack frame.
Numbered ports and colour-coded groups shorten fault finding during moves and changes.
Gland entries suit armoured trunk cable and breakout kits in the same rear opening.
Aluminium construction holds the adapter plate flat under repeated patch cord insertion.
Victor Omondi (verified owner) –
Terminated and labelled, saved us a full day of splicing.
Nancy Wairimu (verified owner) –
Clean
Dennis Kariuki (verified owner) –
Sliding tray is handy during moves and changes.
Rose Adhiambo (verified owner) –
SC duplex couplers seat firmly, no wobble on patching.
Isaac Mwenda (verified owner) –
Filled a full 1U slot, all 48 ports live.
Purity Kerubo (verified owner) –
Fine
George Nyaga (verified owner) –
Pigtails colour coding made mapping quick. Cable clamps are solid.
Juliet Muthoni (verified owner) –
Rack ears lined up first try, no drilling
