SnoMaster ZB15 220V Scroll Compressor for ZBC-15 Ice Maker

Scroll Compressor for Counter-Top Ice Machines

The SnoMaster ZB15 compressor serves as the refrigeration core for the ZBC-15 counter-top ice maker. It delivers 15 kg of bullet ice per 24 hours across three selectable sizes. The hermetic scroll design runs on a 220-240 V single-phase supply at 50 Hz.

The compressor uses R134a or R404A refrigerant and produces approximately 2.37 kW of cooling capacity at ARI conditions. A 15.28 cm³ displacement and permanent split capacitor motor drive the scroll set. Input power sits near 0.76 kW at nominal load.

POE oil lubricates the scroll chamber, and the factory charge holds 280-320 ml. Suction and discharge connections use 1/2-inch and 3/4-inch rotolock fittings. The shell measures roughly 241 mm in diameter and 369 mm in height, and the unit weighs about 15 kg.

Internal motor protection and a discharge temperature sensor guard against overload. The compressor restarts after a three-minute delay to prevent short cycling. Mounting holes match the ZBC-15 base plate, and the terminal box accepts standard spade connectors.

Key Features

• Hermetic Scroll Design
  The orbiting scroll compresses refrigerant with fewer moving parts than reciprocating types.

• 220-240 V Single-Phase Motor
  The PSC motor runs directly from a standard 50 Hz mains supply.

• R134a and R404A Compatibility
  The compressor handles both medium-temperature refrigerants used in ice machines.

• 15.28 cm³ Displacement
  The swept volume supports 15 kg/24 h ice production in the ZBC-15 chassis.

• Rotolock Connections
  1/2-inch suction and 3/4-inch discharge fittings simplify field replacement.

• Internal Overload Protection
  A bimetal switch and discharge sensor trip on excess temperature or current.

• POE Oil Charge
  The polyol ester lubricant suits HFC refrigerants and resists moisture absorption.

• Direct ZBC-15 Fit
  Mounting holes and terminal layout match the ice maker base plate.

Specifications

What’s in the Box

• ZB15 scroll compressor

• Mounting hardware

• Terminal cover

• Installation sheet

Why Choose the ZB15

• The scroll set runs with low vibration and noise compared with reciprocating compressors.

• Rotolock fittings allow direct replacement without brazing adapters.

• The PSC motor draws modest starting current on single-phase supplies.

• POE oil and HFC refrigerant compatibility match modern ice machine requirements.

• Internal protection removes the need for external overload relays in most installations.
