Klüberlub NH1 11-222 Grease 5g Tube NSF H1 Food Grade

Food-grade lubricant for brew group servicing

The NH1 11-222 grease is a 5 g tube of NSF H1 registered lubricant for food-processing and pharmaceutical equipment. It suits brew group seals, guide rails and cam discs on automatic coffee machines. The grease carries ISO 21469 certification for incidental food contact.

The formulation uses paraffinic mineral oil thickened with aluminium complex soap. NLGI grade 2 consistency keeps the grease in place on vertical surfaces and sliding contacts. Worked penetration ranges from 265 to 295 x 0.1 mm at 25°C. The drop point reaches at least 220°C, and service temperature spans -15°C to 100°C.

Water resistance reaches rating 1-90 under DIN 51807 at 90°C for three hours. The grease resists hot and cold water washdown, which suits dairy, beverage and coffee preparation areas. Colour is yellow with a homogeneous texture. The 5 g tube covers several brew group services on domestic and commercial machines.

Apply by brush, spatula or grease gun after cleaning the lubrication point. Remove old grease and coffee residue before the first application. Purge the system during re-lubrication where cleaning is not possible. Store the unopened tube in a dry, frost-free place. Shelf life is approximately 24 months from the date of manufacture.

Compatibility covers Saeco and Philips coffee machine brew groups that specify part 421945031791. The tube also serves Gaggia models that reference the same lubricant. Confirm the service manual before application, because some brew groups use silicone grease instead. Do not mix greases with different thickener systems.

The NSF H1 registration number is 137536. This registration supports compliance with FDA 21 CFR 178.3570 for incidental contact. Operators should still run a HACCP risk analysis for each application. The 5 g tube size suits service kits and technician tool bags.

Key Features

• NSF H1 Registration 137536
  The registration supports compliance with FDA 21 CFR 178.3570 for incidental food contact.

• Aluminium Complex Soap Thickener
  The thickener system holds NLGI 2 consistency on sliding contacts and vertical rails.

• Service Temperature Range

  • Lower service temperature of -15°C
  • Upper service temperature of 100°C
  • Drop point of at least 220°C

• Water Resistance
  The grease holds rating 1-90 under DIN 51807 at 90°C for three hours.

• 5g Service Tube
  The small tube suits brew group maintenance and technician service kits.

• ISO 21469 Certification
  The certification supports hygienic lubrication requirements in food production.

• Coffee Machine Compatibility
  The lubricant serves Saeco, Philips and Gaggia brew groups that specify the part number.

Specifications

What’s in the Box

• 5 g tube of food-grade lubricating grease

Why Choose This Lubricant

• The H1 registration covers incidental contact in food and beverage production.

• NLGI 2 consistency stays on vertical rails and sliding brew group contacts.

• Water resistance supports washdown cleaning in dairy and coffee areas.

• The 5g tube matches service kit quantities and avoids waste on single jobs.

• ISO 21469 certification aligns with hygiene requirements in food plants.

• A 24-month shelf life simplifies spare stock planning for maintenance teams.
