IDP Smart Card Encoder SP S51 Contactless 5122 Module
Original price was: KSh 70,000.00.KSh 65,000.00Current price is: KSh 65,000.00.
IDP Smart Card Encoder SP S51 Contactless 5122 Module
| Brand | IDP |
| Module Model | SP S51 (5122) |
| Technology | Contactless HF RFID |
| Frequency | 13.56 MHz |
| Compatibility | IDP Solid Series Printers |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
IDP SP S51 Encoder
The IDP Smart Card Encoder provides a critical hardware upgrade for high-frequency contactless data transmission within compatible identification card printers. This internal module utilizes the 5122 chipset to facilitate seamless communication between the printer hardware and RFID-enabled smart cards. It operates primarily on the 13.56 MHz frequency. This allows for high-speed data encoding during the standard printing cycle. Consequently, IT departments can produce secure, encrypted credentials without requiring secondary encoding stations.
Key Features
-
Internal Integration Architecture
The hardware mounts directly into the printer chassis to maintain a compact footprint and eliminate external cabling requirements. -
Multi-Protocol Support
- ISO/IEC 14443 Type A and B compliance for broad card compatibility.
- Support for MIFARE, DESFire, and Felica standards.
- ISO/IEC 15693 protocol support for proximity applications.
-
High-Speed Data Throughput
- Internal USB or serial connectivity ensures rapid data transfer rates.
- Synchronous encoding occurs during the ribbon-to-card transfer phase.
Specifications
| Feature | Specification |
|---|---|
| Module Type | Contactless Smart Card Encoder |
| Chipset | S51 / 5122 |
| Frequency | 13.56 MHz (HF) |
| Interface | Internal USB / Serial |
What’s in the Box
- IDP SP S51 Contactless Encoder Module
- Internal Mounting Hardware and Screws
- Interface Connection Cable
- Installation Guide for Technical Staff
Why Choose IDP SP S51 Encoder
- The system utilizes an industrial-grade 5122 chipset to ensure consistent read/write cycles across large card batches.
- Furthermore, the internal mounting prevents physical tampering with the encoding unit, enhancing the security of the credentialing process.
- Network engineers can easily configure the device via the standard IDP printer driver interface without installing third-party middleware.
- Additionally, this component supports field upgrades. Therefore, procurement managers can add encoding capabilities to existing printer fleets as security requirements evolve.
- The unit maintains high MTBF (Mean Time Between Failure) ratings. This reliability minimizes downtime in high-volume production environments.
