Eezi-Awn K9 Roof Rack 1250 x 2000mm for Toyota Prado 120

Expedition Platform for Toyota Prado 120

The Eezi-Awn K9 rack measures 1250 mm wide by 2000 mm long and mounts to the Toyota Land Cruiser Prado 120 roof. Extruded aluminium slats run across the platform, and the side profiles carry structural load. The deck sits about 35 mm above the mounting plane, which keeps wind noise and drag low at highway speed.

The platform uses matte black powder-coated aluminium with fully welded joints. The manufacturer rates the system at roughly 227 kg dynamic and 454 kg static, subject to vehicle roof limits. Ten separate feet share the load across the roof, where many racks use three pairs. That spread reduces point stress on the pinch weld.

Every plank carries twin 8 mm T-slots, and a continuous 6 mm track runs around the perimeter. Those slots accept eye bolts, awning brackets, jerry can holders, shovel mounts and rooftop tent rails without drilling the deck. A wind deflector ships with the rack and trims turbulence at the leading edge.

The proprietary mounting rail sits over the roof pinch-weld trim and reuses the OEM mounting points. Installers do not drill the roof skin. Track-mount feet span 40 mm to 90 mm, and the rail stays on the vehicle when the platform lifts off. That split suits operators who need the rack only on expedition weeks.

Each foot clamps to the factory channel with a captive bolt and a rubber isolator. The isolator absorbs body flex on corrugated roads and limits vibration transfer into the aluminium deck. Installers torque the bolts to the figure printed in the supplied guide and recheck them after the first 500 km.

The deck carries a rooftop tent, recovery boards, jerry cans and storage cases at the same time. Load sits on the welded frame rather than on individual rivets, so the platform resists fatigue over repeated trips. The 2000 mm length covers the full Prado 120 roof and leaves room for a rear awning bracket.

Key Features

• Welded Aluminium Platform
  Fully welded joints and powder-coated extrusion resist flex under uneven loads.

• Low-Profile Deck Geometry
  The 35 mm platform height limits frontal area and wind noise.

• Load Distribution

  • Ten mounting feet spread load across the roof structure.
  • Dynamic rating near 227 kg for travelling loads.
  • Static rating near 454 kg when the vehicle is parked.

• Twin T-Slot Planks
  Two 8 mm slots per slat accept standard overland accessory hardware.

• Perimeter Tie-Down Track
  A 6 mm continuous groove runs the full outer edge for strap anchors.

• Drill-Free Mounting Rail
  The rail clamps to OEM points and leaves the roof skin intact.

• Removable Platform
  The deck lifts free while the low rail remains fixed to the vehicle.

• Wind Deflector
  The supplied deflector cuts turbulence at the front edge of the platform.

Specifications

What’s in the Box

• K9 platform deck assembly

• Vehicle-specific mounting rail set

• Mounting feet and hardware

• Wind deflector

• Installation instructions

Why Choose This Prado 120 Platform

• The welded aluminium deck carries rooftop tents and recovery gear without visible flex.

• Ten feet distribute load across the roof instead of concentrating stress at four points.

• Twin T-slots and the perimeter groove remove the need for custom brackets.

• The removable platform design keeps the vehicle usable between trips.

• A 35 mm profile keeps clearance in low-roof parking structures.
