Eezi-Awn K9-031 TM Roof Rack – 1250 x 2000mm Prado 150 Platform

Expedition Platform Rack for the Prado 150

The Eezi-Awn K9-031 roof rack is a 1250 x 2000 mm aluminium platform built for the Toyota Land Cruiser Prado 150. The kit mounts over the roof pinch-weld trim and uses the factory roof rack points, so no drilling is required. It carries roof tents, jerry cans, recovery boards and awnings on a flat, welded deck.

The platform measures 35 mm thick and uses extruded aluminium with fully welded joints rather than bolted corners. That construction keeps the frame rigid on corrugated track and removes the rattle that bolt-together racks develop. Matte black powder coat covers every component, and the semi-elliptical bottom cross braces cut wind noise at highway speed.

Five 130 mm wide M8 T-slot slats run front to back across the deck. An M6 T-slot runs around the top perimeter with a rounded edge, which accepts eye bolts, tie-down rings and accessory brackets. The standard 65 mm feet place the deck roughly 127 mm above the roofline. Eezi-Awn lists a static capacity near 454 kg and a dynamic capacity near 227 kg, subject to the vehicle roof rating.

Fitting takes about 1.5 hours with basic hand tools, and two people should lift the platform into position. The mounting rail follows the factory roof points, so the rack can be removed and the rail left in place. Confirm the Prado 150 roof load limit before loading the platform to its full dynamic figure.

Key Features

• 1250 x 2000 mm Deck
  The platform gives a long, narrow load floor that runs most of the Prado 150 roofline.

• Fully Welded Aluminium Frame
  Welded joints replace bolted corners for stiffness and quiet operation on rough track.

• M8 T-Slot Slats

  • Five slats at 130 mm wide run front to back
  • Slots accept M8 bolts for accessories at any position
  • M6 perimeter slot carries rings and brackets

• No-Drill Mounting
  The rail sits over the pinch-weld trim and clamps to the OEM roof rack points.

• Low-Profile 35 mm Platform
  The deck adds minimal height and uses aerodynamic edging to reduce drag.

• Semi-Elliptical Cross Braces
  Shaped braces under the deck break up airflow and lower wind noise.

• Corrosion-Resistant Finish
  Anodised and powder-coated aluminium handles coastal and dusty conditions.

• Removable Platform
  The rack lifts off the rail and leaves the low-profile track on the vehicle.

Specifications

What’s in the Box

• K9 platform, 1250 x 2000 mm

• Pair of mounting rails

• Set of K9 feet

• Installation hardware

Why Choose This Prado Platform

• The welded aluminium deck stays stiff under a roof tent and loaded jerry cans.

• Front-to-back slats give a continuous mounting grid for awnings and recovery boards.

• The no-drill rail protects the roof and allows the platform to come off between trips.

• The low 35 mm profile and shaped braces keep wind noise down on long highway legs.

• Anodised and powder-coated aluminium resists corrosion in coastal and dusty use.
