SnoMaster ZBC-20 Control Panel – 200074 Ice Maker Switch Assembly

Replacement Interface for the 20kg Bullet Ice Maker

The SnoMaster ZBC-20 control panel (SKU 200074) is the operator fascia and switch assembly for the ZBC-20 counter-top bullet ice maker. It carries the push-button membrane, the status LED windows and the ribbon lead that mates with the main controller board. Fit it when the overlay cracks, a button loses travel or an indicator stops reporting.

The fascia exposes four functions: ice-size selection, start and stop, cleaning cycle and power. Three LED windows report power, ice full and add water. A green indicator flashes until the operator selects a bullet size, then holds steady through production. The three settings map to S 25 mm, M 28 mm and L 30 mm bullets.

The panel mounts in the upper front of the 415 x 380 x 400 mm chassis, above the lid line. A keyed ribbon connector blocks reversed insertion during service. The sealed overlay resists splash from the 2 kg basket area and wipes clean with a non-abrasive cloth.

The host appliance draws 1.1 A at 230 V/50 Hz and consumes 110 W total. It produces 20 kg per 24 hours across 12-bullet cycles. This replacement fascia carries no refrigeration or water circuit, so no refrigerant handling is involved. Startup runs a portable diagnostic check and reports faults through the LED windows.

Key Features

• Four-Function Push-Button Membrane
  Handles ice-size selection, start/stop, cleaning cycle and power from a single sealed overlay.

• Ice-Size Selection
  Selects small 25 mm, medium 28 mm or large 30 mm bullet sizes before the cycle starts.

• Status LED Windows
  Separate indicators report power, ice full and add water conditions at a glance.

• Flashing Size Prompt
  A green lamp flashes until the operator picks a bullet size, then stays lit during production.

• Keyed Ribbon Interface

  • Polarised connector prevents reversed insertion on the main controller
  • Detachable lead speeds swap-out during field service
  • No soldering required on the replacement assembly

• Front Chassis Mounting
  Fits the upper front of the 415 x 380 x 400 mm cabinet above the lid line.

• Diagnostic Support
  Works with the startup diagnostic check that reports faults through the indicator windows.

• Wipe-Clean Overlay
  The sealed surface tolerates splash from the basket area and cleans with a non-abrasive cloth.

Specifications

What’s in the Box

• 200074 control fascia assembly

• Keyed ribbon lead

• Fitting instructions

Why Choose This Ice Maker Fascia

• A direct part number match removes guesswork when ordering a spare switch assembly.

• The keyed lead lets a technician complete the swap without soldering or board rework.

• Restoring the size prompt and full-basket indicators prevents overflow during service.

• The sealed overlay holds up to daily wipe-down in bar and kitchen environments.

• Keeping the original controller board avoids a full appliance replacement.
