OM3 SC LC Patch Cord 5m Duplex UPC Multimode LSZH
Limited Stock
OM3 SC LC Patch Cord 5m Duplex UPC Multimode LSZH
| Fibre Type | OM3 multimode, 50/125 µm |
| Connector A | SC/UPC duplex |
| Connector B | LC/UPC duplex |
| Length | 5 m |
| Insertion Loss (max) | 0.15 dB per connector |
| Return Loss (min) | 35 dB |
| Jacket Material | LSZH |
| Jacket Colour | Aqua |
| Cable Diameter | 1.8 mm |
| Operating Wavelength | 850 nm / 1300 nm |
| Operating Temperature | -20 °C to 70 °C |
| Polarity | Crossed, TIA-568 Type-B |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Multimode Duplex Jumper for 10G Links
The OM3 SC LC patch cord is a 5-metre duplex multimode assembly that connects SC/UPC and LC/UPC interfaces. It uses 50/125 µm OM3 fibre with a laser-optimised core for 10 Gb/s transmission over 300 metres. Aqua LSZH jacketing identifies the multimode grade and limits smoke emission.
Each connector uses a ceramic ferrule with UPC polish. Maximum insertion loss reaches 0.15 dB per connector, and minimum return loss measures 35 dB. The 1.8 mm twin-fibre zip cord carries aramid strength members and a low-smoke zero-halogen outer jacket.
Typical deployment links SFP+ transceivers, patch panels and switches inside data centres and campus cabinets. The cord operates from -20 °C to 70 °C and meets IEC 61753-1 and TIA-568 polarity requirements. Factory termination removes field polishing from the installation schedule.
Key Features
OM3 Laser-Optimised Fibre
The 50/125 µm core supports 10 Gb/s Ethernet to 300 m and 40/100 Gb/s to 100 m with VCSEL sources.SC/UPC to LC/UPC Termination
- Ceramic ferrules with UPC polish on both ends
- Maximum insertion loss of 0.15 dB per connector
- Minimum return loss of 35 dB
LSZH Twin-Fibre Jacket
The 1.8 mm zip cord uses low-smoke zero-halogen material for indoor plenum and riser routes.5-Metre Reach
The 5 m length spans adjacent racks, patch panels and overhead cable trays without excess slack.Aqua Grade Identification
The aqua jacket colour marks the assembly as OM3 multimode for quick port mapping.Factory Testing
Each assembly is optically tested and supplied with an insertion loss record before dispatch.Duplex Polarity
The cord follows TIA-568 Type-B crossed polarity for duplex LC and SC transceiver pairs.
Specifications
| Feature | Specification |
|---|---|
| Fibre Type | OM3 multimode, 50/125 µm |
| Connector A | SC/UPC duplex |
| Connector B | LC/UPC duplex |
| Length | 5 m |
| Insertion Loss (max) | 0.15 dB per connector |
| Return Loss (min) | 35 dB |
| Jacket Material | LSZH (low smoke zero halogen) |
| Jacket Colour | Aqua |
| Cable Diameter | 1.8 mm |
| Operating Wavelength | 850 nm / 1300 nm |
| Bandwidth (EMB) | ≥ 2000 MHz·km at 850 nm |
| Operating Temperature | -20 °C to 70 °C |
| Storage Temperature | -20 °C to 70 °C |
| Polarity | Crossed, TIA-568 Type-B |
| Standards | IEC 61753-1, TIA-568 |
| Packaging | Individual poly bag |
What’s in the Box
5 m OM3 SC/UPC to LC/UPC duplex patch cord
Insertion loss test record
Why Choose This OM3 Assembly
The 5 m span covers top-of-rack to patch-panel links without cable management clutter.
Laser-optimised core supports 10G SFP+ and 40G QSFP+ uplinks on the same fibre.
LSZH jacket reduces toxic smoke in enclosed cabinets and riser shafts.
Pre-terminated ends remove polishing and fusion splicing from the schedule.
Aqua jacketing speeds up port identification during moves and changes.
UPC ferrules maintain low reflectance across repeated mating cycles.
