OEM SC-SC APC OM3 3m Fiber Patch Cord
WhatsApp for availability
OEM SC-SC APC OM3 3m Fiber Patch Cord
| Feature | Specification |
|---|---|
| Fiber Grade | OM3 Multimode |
| Connectors | SC/APC to SC/APC |
| Length | 3 Meters |
| Jacket | LSZH Aqua |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
OEM SC-SC APC Patch Cord
The OEM SC APC OM3 fiber jumper facilitates high-bandwidth data transmission within enterprise data centers and telecommunications rooms. This three-meter assembly features 50/125µm laser-optimized multimode glass. It supports 10 Gigabit Ethernet applications over distances up to 300 meters at 850nm. The integration of Angled Physical Contact connectors distinguishes this cable from standard UPC variants. This specific polish reduces back reflection significantly. The cable meets stringent TIA/EIA standards for optical performance.
Key Features
Angled Physical Contact Polish
The 8-degree angle polish on the SC connectors minimizes back reflection to improve signal stability in sensitive optical links.Laser-Optimized Multimode Fiber
- Supports 2000 MHz*km effective modal bandwidth at 850nm.
- Compatible with VCSEL laser sources and legacy LED systems.
Low Smoke Zero Halogen Jacket
The LSZH outer sheath restricts the release of toxic gases and smoke during combustion in poorly ventilated areas.Precision Ceramic Ferrules
- High-quality zirconia ferrules ensure precise core-to-core alignment.
- Maintains low insertion loss through repeated mating cycles.
Specifications
| Feature | Specification |
|---|---|
| Fiber Type | OM3 Multimode 50/125µm |
| Connector Type | SC/APC to SC/APC |
| Length | 3 Meters (9.8 ft) |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 60 dB |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Operating Wavelength | 850nm / 1300nm |
| Jacket Color | Aqua |
What’s in the Box
1 x 3m SC/APC to SC/APC OM3 Multimode Fiber Patch Cord
Test Result Report
Why Choose OEM SC-SC APC Patch Cord
The SC-SC APC OM3 assembly addresses specific return loss requirements in high-sensitivity multimode systems. Standard UPC connectors reflect more light back toward the source. This interference degrades signal integrity in high-speed laser-driven links. By employing an 8-degree angle polish, this cable directs reflected light into the fiber cladding. This mechanism preserves the extinction ratio of the optical transmitter. Furthermore, the 50/125 micron core supports legacy and modern VCSEL sources. The aqua-colored jacket allows for immediate identification within cable management trays. Each unit undergoes rigorous interferometric testing to verify geometry and vertex offset. This ensures reliable mating with standard SC adapters. The three-meter length provides sufficient slack for cross-connects without creating excessive congestion.
