OEM Outdoor Fiber OS2 Single Mode Armored
WhatsApp for availability
OEM Outdoor Fiber OS2 Single Mode Armored
| Feature | Specification |
|---|---|
| Fiber Class | OS2 Single Mode |
| Construction | Armored Loose Tube |
| Jacket | HDPE UV-Resistant |
| Environment | Outdoor/Direct Burial |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
OEM Outdoor Fiber
The OEM Outdoor Fiber OS2 facilitates reliable long-range data transmission across campus and metropolitan area networks. This cable utilizes a loose tube architecture to isolate fibers from environmental fluctuations. Each fiber strand resides within a gel-filled buffer tube to prevent moisture ingress. The design prioritizes structural integrity during high-tension pulls in underground conduits. Engineers specify these cables for harsh external environments where temperature stability is critical. The outer high-density polyethylene jacket resists ultraviolet radiation and chemical exposure. Internal water-blocking yarns provide a secondary layer of protection against longitudinal water penetration. This construction ensures signal consistency over spans exceeding 10 kilometers without significant attenuation. The cable remains flexible enough for complex pulls while maintaining its structural profile under load.
Mechanical protection comes from a corrugated steel tape armor layer located beneath the jacket. This metallic barrier guards against rodent damage and accidental mechanical impact during excavation. It also provides excellent crush resistance for direct burial applications. The cable maintains a minimum bend radius that allows for efficient routing within splice enclosures and patch panels. Optical performance meets ITU-T G.652.D standards for low water peak performance. This allows for operation across the entire 1260 nm to 1625 nm wavelength range. The cable supports high-speed protocols including 10G, 40G, and 100G Ethernet. Robust tensile strength members, often made of glass-reinforced plastic or steel, handle the stresses of aerial or duct installations. These components prevent fiber elongation during the installation process. Integration into existing infrastructure requires standard LC, SC, or ST connectors. The color-coded buffer tubes follow TIA/EIA-598 standards for rapid fiber identification. This systematic approach reduces splicing errors during field termination. Reliability remains high across a wide operating temperature range from -40°C to +70°C. Consequently, the cable maintains performance in extreme climates without signal degradation.
Key Features
Corrugated Steel Armor
Provides a physical barrier against rodent gnawing and mechanical crushing in direct burial environments.Water-Blocking Technology
- Gel-filled loose tubes prevent moisture contact with glass
- Dry water-swellable yarns stop longitudinal water migration
UV-Resistant HDPE Jacket
High-density polyethylene material ensures long-term durability against sunlight exposure and soil chemicals.Low Water Peak Fiber
- Complies with ITU-T G.652.D specifications
- Eliminates attenuation spikes in the E-band wavelength
Specifications
| Feature | Specification |
|---|---|
| Fiber Type | OS2 Single Mode |
| Core Count | 12-Core (Standard Configuration) |
| Jacket Material | High-Density Polyethylene (HDPE) |
| Armor Type | Corrugated Steel Tape (CST) |
| Attenuation @ 1310nm | ≤ 0.35 dB/km |
| Attenuation @ 1550nm | ≤ 0.22 dB/km |
| Operating Temperature | -40°C to +70°C |
| Tensile Strength (Short Term) | 2700 N |
| Crush Resistance | 2200 N/100mm |
What’s in the Box
OEM Outdoor Fiber Cable Spool
Technical Specification Sheet
Test Result Documentation
Why Choose OEM Outdoor Fiber
Maintains low signal loss over long-haul distances using G.652.D compliant glass.
Withstands environmental stress through multi-layered moisture and mechanical protection.
Simplifies identification during installation with standardized color-coded buffer tubes.
Supports direct burial or duct installation without requiring additional conduit protection.
Josphat Njoroge (verified owner) –
The armor on this OS2 fiber is serious. We had issues with rodents at our site in Athi River chewing through the standard jackets, but this armored version has held up well for three months now. Signal is very stable even over the 2km run we installed.
Mercy Wambui (verified owner) –
Good quality for the price. Using it for our backhaul links in the CBD. It’s a bit heavy because of the protection, so make sure your technicians are ready for the pull, but the performance is solid.
Kelvin Otieno (verified owner) –
Installation was smooth. The cable isn’t as stiff as I expected despite the armoring, so navigating the bends in the conduits wasn’t a headache. Splicing was straightforward and the loss is well within OS2 standards. Good stuff.
Brian Kipkorir (verified owner) –
Product is okay and works as advertised, but the wooden spool arrived a bit damaged on one side. Luckily the fiber itself wasn’t affected. Just be careful when offloading.
Fatuma Hassan (verified owner) –
Very reliable single mode fiber for outdoor runs. No issues with moisture or heat so far.
Evans Omari (verified owner) –
We used this for an outdoor CCTV setup across a large compound in Karen. The armored casing gives us peace of mind against accidental cuts during gardening or maintenance. It’s a bit more expensive than the non-armored ones but definitely worth it for the durability. Proper industrial grade.
