OEM SC-SC APC 15m OM3 Fiber Patch Cable
WhatsApp for availability
OEM SC-SC APC 15m OM3 Fiber Patch Cable
| Feature | Specification |
|---|---|
| Fiber Class | OM3 Multimode |
| Connectors | SC to SC |
| Polish | APC |
| Length | 15 Meters |
| Bandwidth | 10Gbps Support |
Shipping & Delivery
Delivery
We deliver to the address you provide. Nairobi CBD is often same-day on business days.
Nairobi CBD or Kenya-wide
Free CBD ≥ KES 20,000; else from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
SC-SC APC OM3 Fiber Jumper
The OEM SC-SC APC OM3 fiber patch cable enables high-speed data transmission across 15-meter spans in enterprise network environments. This multimode optical assembly utilizes laser-optimized 50/125 micron fiber to support 10 Gigabit Ethernet applications. The integration of SC connectors with an Angled Physical Contact (APC) polish ensures low back-reflection and stable signal integrity. This specific configuration meets the demands of high-density patching in data centers and telecommunications rooms. The cable operates primarily at the 850nm wavelength, optimized for Vertical-Cavity Surface-Emitting Laser (VCSEL) light sources.
Engineers utilize this 15-meter multimode lead to bridge the gap between core switches and distribution frames. The OM3 classification provides a minimum modal bandwidth of 2000 MHz·km at 850nm. This bandwidth capacity allows for reliable 10Gbps throughput over distances up to 300 meters. The SC connector housing employs a push-pull latching mechanism for secure engagement. Consequently, the physical connection remains stable even in high-vibration environments or crowded rack configurations. The APC polish on the ferrules reduces optical return loss, which is critical for maintaining signal quality in sensitive transceiver modules.
Key Features
Laser-Optimized Core
The 50/125µm multimode core facilitates high-bandwidth data transmission using VCSEL technology.Advanced Connector Geometry
- SC-to-SC interface with push-pull latching
- APC polish for reduced back-reflection
- Precision ceramic ferrules for alignment
LSZH Safety Rating
The Low Smoke Zero Halogen jacket reduces toxic gas emissions during thermal decomposition.Optical Performance Standards
- Insertion loss maintained below 0.3dB
- Return loss exceeding 50dB due to APC geometry
- TIA/EIA-492AAAC compliance
Specifications
| Feature | Specification |
|---|---|
| Brand | OEM |
| Fiber Type | Multimode OM3 |
| Core/Cladding | 50/125µm |
| Connector Type | SC to SC |
| Polish Type | APC (Angled Physical Contact) |
| Length | 15 Meters |
| Jacket Material | LSZH (Aqua) |
| Bandwidth | 2000 MHz·km @ 850nm |
| Insertion Loss | ≤ 0.3 dB |
What’s in the Box
1 x 15m SC-SC APC OM3 Multimode Fiber Patch Cable
Individual Test Report
Protective Dust Caps
Why Choose SC-SC APC OM3 Fiber Jumper
Supports 10GbE networking standards up to 300 meters for enterprise backbone links.
Reduces signal degradation through high-precision APC ferrule polishing.
Complies with international fire safety standards via the halogen-free outer sheath.
Provides a 15-meter reach for flexible routing within large data center rows.
