OEM 24-Port LC/UPC Duplex OS2 Fiber Patch Panel
WhatsApp for availability
OEM 24-Port LC/UPC Duplex OS2 Fiber Patch Panel
| Feature | Detail |
|---|---|
| Form Factor | 1U Rack Mount |
| Fiber Type | OS2 Single-mode |
| Connector | LC/UPC Duplex |
| Capacity | 24 Ports (48 Fibers) |
| Included | Adapters and Pigtails |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
OEM 24-Port Fiber Panel
The OEM 24-Port LC/UPC Patch provides a standardized 1U rack-mount solution for high-density single-mode fiber terminations. This enclosure supports up to 24 duplex LC connections, facilitating 48 individual fiber strands within a compact 19-inch form factor. Every unit comes pre-loaded with OS2-rated pigtails and duplex adapters featuring Zirconia ceramic alignment sleeves. The chassis utilizes a sliding tray mechanism to allow technicians full access to the internal splice management area. Four rear cable entry points feature protective grommets to secure incoming trunk cables. The internal layout prioritizes bend radius protection for 9/125μm single-mode cores to prevent signal attenuation. Each duplex port includes a dust cap to maintain optical interface cleanliness before deployment. This hardware serves as a critical cross-connect point in enterprise data centers and telecommunication rooms.
Key Features
Standardized 1U Form Factor
The enclosure fits all standard 19-inch relay racks and server cabinets using included mounting hardware.Optical Performance Standards
- Insertion loss remains below 0.3dB for all mated pairs.
- Return loss exceeds 50dB due to the UPC precision polishing.
- Zirconia ceramic sleeves ensure consistent axial alignment for minimal signal variance.
Physical Chassis Construction
The heavy-duty cold-rolled steel housing provides mechanical protection and structural rigidity in high-density environments.Fiber Management System
- Internal splice trays organize 48 fusion splices with integrated heat-shrink holders.
- TIA-598-A color-coded pigtails simplify fiber identification and splicing workflows.
- Routing hoops maintain a 30mm minimum bend radius for optical integrity.
Specifications
| Feature | Specification |
|---|---|
| Rack Units | 1U (19-inch) |
| Adapter Type | LC/UPC Duplex |
| Fiber Category | OS2 Single-mode (9/125μm) |
| Port Count | 24 Duplex (48 Fibers) |
| Material | Cold-rolled Steel |
| Pigtail Length | 1.5 Meters |
| Operating Temperature | -20°C to +60°C |
What’s in the Box
1U Rack Mount Fiber Enclosure
24 LC/UPC Duplex Single-mode Adapters
48 OS2 9/125μm Fiber Pigtails
Splice Trays and Protection Sleeves
Rack Mounting Screw Kit
Why Choose OEM 24-Port Fiber Panel
The pre-installed components reduce labor time during on-site infrastructure deployment.
OS2-rated pigtails support long-haul 10G, 40G, and 100G Ethernet applications over single-mode fiber.
Consequently, the robust steel design protects sensitive fusion splices from accidental mechanical damage in shared racks.
Numerical labeling on the front faceplate streamlines port mapping and future network troubleshooting.
Kevin Omondi (verified owner) –
Decent 24-port panel. The OS2 duplex adapters fit tightly which is what you want for a stable connection. My only small issue was the cable management tray at the back is a bit tight if you are using thicker trunk cables, but for standard patch cords, it is fine. It is a reliable unit for the price point.
Josphat Mwangi (verified owner) –
The build quality on this panel is actually very solid. I used it for a small site office in Upper Hill and the LC adapters are well-aligned, no issues with insertion loss when testing. Having the pigtails included in the box saves a lot of time during termination. Good value for money compared to the high-end brands.
Brenda Akoth (verified owner) –
Safi sana. Installed it last week and it’s working perfectly for our fiber backbone. Delivery was quick to our shop in CBD.
