GN-220HS Back Bar Cooler 220L Two Sliding Glass Doors 2-8°C 280W

Two-Door Bottle Display Cabinet

The GN-220HS back bar cooler is a two-door bottle display cabinet rated at 220 litres. It holds product between 2 °C and 8 °C with a forced-air cooling circuit. Two transparent sliding doors give staff front access without a door swinging into a narrow service aisle.

The cabinet measures 900 x 505 x 895 mm and runs on 220 V at 50 Hz. A 280 W compressor and fan assembly circulate cold air across the embossed aluminium interior. Two adjustable shelves set the internal layout for bottles, cans and mixers.

Sliding doors ride on nylon runners, which removes the clearance a hinged door demands. LED strips light the shelves along the full height so labels read at a glance. The embossed aluminium liner reflects light and resists scratching from bottle bases.

Site the unit on a level floor with at least 100 mm clearance at the rear grille. Let it stand upright for a few hours before first start so the compressor oil settles. Set the thermostat, load stock, then check the door track for smooth travel.

Key Features

• 220-litre internal volume
  The cabinet holds bottled beer, soft drinks and mixers across two adjustable shelves.

• 2 °C to 8 °C operating band
  The thermostat range covers chilled serving temperature for packaged beverages.

• Transparent sliding doors

  • Two glass panels on nylon runners.
  • No swing clearance required at the front.
  • Full-width visibility of the top and bottom shelves.

• Forced-air cooling
  The fan moves cold air across the cabinet to hold an even temperature top to bottom.

• 280 W compressor
  The hermetic compressor runs on a 220 V, 50 Hz single-phase supply.

• Embossed aluminium liner
  The textured interior reflects light and resists scuffing from bottle bases.

• LED shelf lighting
  Low-heat strips illuminate product labels without adding load to the cooling circuit.

• Compact 900 mm width
  The 900 x 505 x 895 mm footprint fits beneath a standard back bar counter run.

Specifications

What’s in the Box

• GN-220HS two-door bottle display cabinet

• Two adjustable wire shelves

Why Choose This Bottle Cooler

• Sliding doors keep the service aisle clear in a tight back bar layout.

• Forced-air distribution holds a stable reading across both shelves.

• The aluminium liner cleans down quickly and tolerates daily bottle handling.

• LED strips cut heat gain compared with incandescent cabinet lighting.

• At 900 mm wide, the chassis drops under most standard counter heights.

• Two adjustable shelves reset the internal layout for cans or tall bottles.
