12.5 x 12.5 x 12 cm ABS Enclosure – Black Project Box

Molded Housing for Electronic Assemblies

The ABS enclosure black is a 12.5 x 12.5 x 12 cm cube moulded from acrylonitrile butadiene styrene. It houses printed circuit boards, power supplies, relay modules and small control assemblies. The black finish limits visible scuffing on bench and cabinet installations.

ABS delivers high impact resistance across a wide temperature band. The polymer resists dilute acids, alkalis and most household solvents. It machines and drills cleanly, so installers cut cable entries and mounting holes on site without cracking the wall. The material also accepts self-tapping screws and threaded inserts.

The cube geometry provides 1,953 cm³ of internal volume before wall thickness. That space accepts a PCB up to roughly 110 x 110 mm with clearance for standoffs and terminal blocks. Four internal bosses accept self-tapping PCB mounts, and the base sits flat on a shelf or panel.

The lid seats on a moulded lip and closes with screws at the corners. A tongue-and-groove joint limits dust ingress along the seam. The enclosure suits indoor bench equipment, DIN-rail adapters and wall-mounted control nodes. It does not carry an outdoor IP rating without additional gasket and cable gland hardware.

Key Features

• 12.5 cm Cube Format
  The equal-sided body accepts square PCBs and stacked module assemblies without wasted depth.

• ABS Thermoplastic Body
  The moulded shell absorbs impact and resists cracking under normal bench handling.

• Black Matte Finish
  The dark surface hides handling marks and reduces reflection in control cabinets.

• Internal PCB Mounting

  • Four moulded bosses for self-tapping screws
  • Approx. 1,953 cm³ internal volume
  • Accepts PCBs up to roughly 110 x 110 mm
  • Flat base for shelf or panel mounting

• Screw-Down Lid
  Corner screws clamp the lid against a moulded lip for a close seam.

• Field Machinable
  The ABS wall drills and cuts cleanly for cable entries, connectors and ventilation slots.

• Chemical Resistance
  The polymer resists dilute acids, alkalis and common solvents used in equipment rooms.

Specifications

What’s in the Box

• ABS enclosure body

• Matching lid

• Corner screws

Why Choose This Enclosure

• The cube format fits square PCBs and stacked modules without excess depth.

• ABS absorbs impact and resists cracking during drilling and handling.

• The black matte shell hides scuffs in cabinet and bench installations.

• Internal bosses accept self-tapping PCB mounts without a separate carrier plate.

• The screw-down lid opens for service access and reseats without tools beyond a driver.

• The material machines cleanly for custom connector cutouts.
