USB 2.5 External Case SATA III to USB 3.0 Tool-Free Enclosure

Portable SATA Drive Housing

The USB 2.5 External Case converts a bare 2.5-inch SATA drive into a bus-powered portable unit. It accepts 7 mm and 9.5 mm drive heights. A slide-off lid gives tool-free access to the SATA connector. The ABS shell measures 128 x 78 x 14 mm and weighs 48 g empty.

A USB 3.0 Micro-B port links the housing to the host at 5 Gbps. The bridge board supports UASP and trims command overhead on Windows 8 and later, macOS and Linux. It falls back to BOT for older systems. The SATA interface runs at 6 Gbps and negotiates SATA I, II and III drives automatically.

Bus power comes from the host port at 5 V and up to 900 mA. No external adapter is needed for most 2.5-inch drives. A blue LED shows link and activity. The caddy supports drives up to 4 TB and ships with a 50 cm USB 3.0 cable. Vent slots sit on both sides to move heat away from the bridge board.

Key Features

• USB 3.0 5 Gbps Bridge
  The bridge board moves data between the SATA drive and the host at up to 5 Gbps.

• Drive Compatibility

  • Fits 7 mm and 9.5 mm 2.5-inch drives
  • Accepts SATA I, SATA II and SATA III units
  • Supports drive capacities up to 4 TB

• UASP Acceleration
  USB Attached SCSI Protocol reduces command overhead on modern operating systems.

• Tool-Free Slide Lid
  The lid slides off by hand and exposes the SATA connector without screws.

• Bus-Powered Operation
  The unit draws 5 V at up to 900 mA from the host and needs no wall adapter.

• Activity LED
  A blue indicator shows link status and read or write activity on the drive.

• Ventilated Shell
  Side slots move air across the bridge board during long transfer sessions.

• Portable Footprint
  The 128 x 78 x 14 mm body slips into a laptop bag alongside the drive cable.

• Plug-and-Play Drivers
  The unit uses native USB mass storage drivers, so no software install is required.

Specifications

What’s in the Box

• 2.5-inch SATA enclosure

• USB 3.0 Micro-B cable, 50 cm

• Quick start guide

Why Choose This Drive Housing

• Reuses spare 2.5-inch drives as portable storage without a desktop bay.

• UASP support lifts sequential throughput on current operating systems.

• Bus power removes the need for a separate adapter at the desk or on site.

• The tool-free lid allows quick drive swaps during data migration.

• The ABS shell and vent slots suit travel between office and home.

• UASP and BOT fallback keeps the unit usable on older hosts.
