Siemon CAT6 Dual Faceplate Double Gang 2-Port with Modules White

Double-Gang Outlet for Structured Cabling

The Siemon CAT6 dual faceplate is a double-gang assembly that carries two Category 6 modules for wall-mounted voice and data outlets. It combines a flame-retardant thermoplastic plate with phosphor bronze contacts plated in 50 micro-inches of gold over nickel. The factory-assembled unit arrives ready for termination.

The plate measures 114.3 mm high by 69.85 mm wide and fits standard double-gang electrical boxes and low-voltage mounting brackets. Each module uses 110 IDC termination and supports T568A or T568B wiring. The contacts handle up to 1 Gbps data rates across a 250 MHz bandwidth window.

High-impact thermoplastic resists cracking during installation and meets UL94V-0 flammability requirements. Operating temperature spans -10 °C to 60 °C, and storage extends from -40 °C to 70 °C. The assembly carries UL listing, ETL verification and RoHS compliance. Designated label fields sit above each port for circuit identification.

Key Features

• Double-Gang Two-Port Layout
  The plate accepts two MAX6 modules and mounts to standard double-gang boxes or low-voltage brackets.

• Pre-Assembled CAT6 Modules
  Each port ships with a Category 6 jack rated for 250 MHz and 1 Gbps throughput.

• 110 IDC Termination

  • Standard single-position 110 tooling completes conductor termination
  • T568A and T568B colour codes printed on each module
  • Phosphor bronze contacts with 50 micro-inch gold over nickel plating

• Flame-Retardant Thermoplastic
  The high-impact plate meets UL94V-0 and resists deformation during punch-down work.

• Port Identification Fields
  Label windows above each opening accept printed circuit designations.

• Backward Compatibility
  The modules interoperate with Category 5e and Category 5 cabling systems.

Specifications

What’s in the Box

• Double-gang faceplate

• Two CAT6 MAX6 modules

• Mounting screws

Why Choose This Outlet Assembly

• The pre-loaded two-port layout removes separate module ordering and snap-in steps.

• Gold-plated phosphor bronze contacts hold stable resistance through repeated patching.

• Double-gang format provides extra room for cable dressing behind the plate.

• Printed label windows simplify port tracing during moves and audits.

• The flame-retardant plate satisfies commercial wall-outlet safety requirements.
