Panatron 8-Port Extension Card for PABX Systems 8 Analog Ports

Analog Extension Module for Panatron PABX

The Panatron 8-Port Extension adds eight analog extension lines to a compatible Panatron PABX chassis. Each port accepts a standard telephone handset for internal calling. The card seats in a dedicated expansion slot and draws power from the host system.

The module supports eight internal extension ports for office handsets. It carries voice traffic through the existing PABX backplane. Installation requires no external power supply or additional cabling beyond the extension runs. The card operates between 0°C and 40°C at 10-90% relative humidity, non-condensing.

The faceplate exposes eight RJ-11 ports for telephone connection. The card communicates with the PABX processor over the internal bus. It supports call transfer, forwarding and intercom functions handled by the host system. The plug-and-play design recognises the card on insertion and maps the ports to the extension numbering plan.

Key Features

• Eight Analog Extension Ports
  The card provides eight RJ-11 interfaces for standard analog telephones.

• Panatron PABX Compatibility
  The module seats in dedicated expansion slots on compatible Panatron systems.

• Internal Bus Power

  • Draws operating power from the host PABX chassis
  • No external adapter or separate mains feed required
  • Faceplate LEDs indicate port activity and link status

• Plug-and-Play Recognition
  The PABX processor detects the card on insertion and assigns extension numbers automatically.

• Voice Feature Support
  Connected handsets use call transfer, forwarding, hold and intercom functions from the host system.

• Compact Expansion Format
  The card occupies a single expansion slot and keeps additional extension hardware inside the PABX enclosure.

• Environmental Range
  The module operates from 0°C to 40°C at 10-90% RH without condensation.

• RJ-11 Port Layout
  Eight modular jacks line the faceplate for straightforward punch-down or patch-cord termination.

Specifications

What’s in the Box

• PABX extension card

• Mounting screws

• Installation guide

Why Choose the Panatron Extension Module

• Adds eight internal extensions without replacing the existing PABX chassis.

• Keeps telephone hardware inside the central cabinet for cleaner office wiring.

• Uses host power and bus signalling, so no separate adapter is needed.

• Supports standard analog handsets already deployed across the office.

• Scales internal communication capacity as headcount grows.

• Fits compatible Panatron systems with a single-slot expansion footprint.
