Hikvision DS-1PTS72SCAL SC/APC Single Mode Pigtail 1m
Limited Stock
Hikvision DS-1PTS72SCAL SC/APC Single Mode Pigtail 1m
| Connector | SC/APC, green, 8° endface |
| Fiber mode | Single mode G657A2 |
| Length | 1 m |
| Buffer | 900 µm tight buffer |
| Jacket | Yellow LSZH |
| Insertion loss | 0.2 dB max |
| Return loss | 60 dB min |
| Operating temperature | -40 °C to +70 °C |
| Standards | IEC 61754-4-2002, RoHS 2.0 |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Angled Contact Fiber Termination
The Hikvision SC/APC Pigtail terminates a single-mode fiber with an angled physical contact connector for low-reflection links. It ships in a 1 m length for splice cassettes and patch panels. The G657A2 fiber supports bend-insensitive routing.
A 900 µm tight buffer protects the fiber, and the yellow LSZH jacket meets indoor safety requirements. Maximum insertion loss reaches 0.2 dB, and return loss stays at 60 dB or better. The simplex SC/APC connector uses a green body and an 8° polished endface.
Operating temperature spans -40 °C to +70 °C. The assembly survives more than 500 mating cycles and tolerates a 20D dynamic bend radius. Factory termination removes field polishing, and the unit complies with IEC 61754-4-2002.
Key Features
G657A2 Bend-Insensitive Fiber
The single-mode core resists attenuation loss at tight radii for compact enclosure routing.SC/APC Angled Connector
The 8° endface geometry pushes return loss to 60 dB and limits back-reflection in high-speed links.Factory-Terminated Simplex Tail
- 900 µm tight buffer protects the bare fiber
- Yellow LSZH jacket meets indoor safety requirements
Low Insertion Loss
Maximum 0.2 dB insertion loss preserves optical power budget across the splice point.Wide Operating Range
The pigtail operates from -40 °C to +70 °C in cabinets and wall enclosures.Mechanical Durability
Rated for more than 500 mating cycles with a 20D dynamic and 10D static bend radius.Standards Compliance
Termination follows IEC 61754-4-2002 for SC connector interfaces.RoHS 2.0 Conformant
The assembly meets restricted substance limits for enterprise and campus installations.
Specifications
| Feature | Specification |
|---|---|
| Model | DS-1PTS72SCAL |
| Connector type | SC/APC (green, 8° endface) |
| Fiber mode | Single mode |
| Fiber type | G657A2 |
| Length | 1 m |
| Body style | Simplex |
| Buffer diameter | 900 µm |
| Jacket color | Yellow |
| Jacket material | LSZH |
| Max insertion loss | 0.2 dB |
| Min return loss | 60 dB |
| Operating temperature | -40 °C to +70 °C |
| Bend radius | 20D dynamic, 10D static |
| Durability | >500 mating cycles |
| Reference standard | IEC 61754-4-2002 |
| Compliance | RoHS 2.0 |
| Packaging | 1 unit per bag |
What’s in the Box
One Hikvision DS-1PTS72SCAL SC/APC single mode pigtail, 1 m
Why Choose the Hikvision Fiber Tail
The angled connector keeps return loss low in GPON and point-to-point links.
Factory polishing removes field termination variability from splice trays.
The 900 µm buffer fits standard splice protectors and cassettes.
LSZH jacket limits smoke and halogen output in indoor pathways.
G657A2 fiber handles tight bends without macro-bend loss.
RoHS 2.0 compliance supports procurement policies for enterprise rollouts.
