HD-15 VGA Cable 50m White Male to Male Multi-Shielded Analog Video
Original price was: KSh 4,900.00.KSh 4,200.00Current price is: KSh 4,200.00. ex VAT
HD-15 VGA Cable 50m White Male to Male Multi-Shielded Analog Video
| Connectors | HD-15 male to HD-15 male |
| Length | 50 m |
| Colour | White |
| Signal type | Analog RGBHV with H/V sync |
| Max resolution | 800 x 600 at 60 Hz |
| Bandwidth | 75 MHz |
| Shielding | Multi-layer foil plus braid |
| Cable diameter | 11 mm |
| Operating temperature | -30 °C to 90 °C |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Analog Video Lead for Long Fixed Installs
The HD-15 VGA Cable 50m carries analog RGBHV video between a source and a display across a long fixed run. Two HD-15 male connectors terminate the assembly, and multi-layer foil and braid shielding protect the signal lanes.
The assembly handles up to 800 x 600 at 60 Hz with a 75 MHz baseline bandwidth. Armored PVC jacketing brings the outer diameter to 11 mm, and the finished cable weighs about 3.5 kg. Minimum flex radius measures eight times the cable diameter.
Passive VGA degrades well before 50 m, so plan an inline booster or extender for usable output at full length. The sheath tolerates -30 °C to 90 °C and resists abrasion in floor boxes, risers and industrial control rooms. Label both ends before pulling through conduit.
Key Features
HD-15 Male Connectors
High-density 15-pin plugs mate with standard VGA ports on PCs, monitors, projectors and KVM switches.Multi-Layer Shielding
- Foil wrap blocks high-frequency noise from adjacent mains circuits
- Reinforced braid drains low-frequency interference along the run
- Both layers limit crosstalk between the RGB and sync conductors
Full 50 Metre Span
One continuous assembly reaches between distant racks, podiums and perimeter displays without a coupler.Armored PVC Jacket
The 11 mm sheath resists abrasion and compression in trunking, floor boxes and industrial control rooms.Analog RGBHV Signalling
Separate red, green, blue, horizontal sync and vertical sync conductors carry legacy video formats.Wide Thermal Tolerance
The jacket holds from -30 °C to 90 °C, which covers unheated plant rooms and roof voids.
Specifications
| Feature | Specification |
|---|---|
| Connector A | HD-15 male (VGA/SVGA) |
| Connector B | HD-15 male (VGA/SVGA) |
| Cable length | 50 m |
| Jacket colour | White |
| Signal type | Analog RGBHV with H/V sync |
| Maximum resolution | 800 x 600 at 60 Hz |
| Bandwidth | 75 MHz baseline |
| Shielding | Multi-layer foil plus reinforced braid |
| Outer sheath | Armored PVC |
| Cable diameter | 11 mm |
| Gross weight | Approximately 3.5 kg |
| Minimum flex radius | 8x cable diameter |
| Operating temperature | -30 °C to 90 °C |
| Compliance | VESA basic, RoHS |
What’s in the Box
50 m HD-15 male to male VGA cable, white
Protective connector caps
Why Choose This VGA Lead
A single 50 m length removes the coupler losses that stacked short leads introduce.
Foil and braid layers keep the sync pulses clean where power cabling shares the same tray.
The armored sheath survives drag friction during first fix and later cable moves.
White jacketing blends with painted walls and ceiling voids in finished rooms.
Male-to-male termination plugs directly into source and display, with no gender changer.
RoHS-compliant materials suit procurement requirements in public sector tenders.
