Ugreen US121 Repeater Cable USB 2.0 Active Extension 10m, A Male to A Female, 480 Mbps

Active USB Extension for Long Runs

The Ugreen US121 repeater cable carries USB 2.0 traffic between a host and a peripheral across a 10-metre run. An FE1.1s booster chip sits inside the female connector shell and regenerates the differential data pair. The assembly terminates in a USB-A male plug at one end and a USB-A female socket at the other.

Throughput holds at the USB 2.0 ceiling of 480 Mbps and falls back to USB 1.1 devices without configuration. The booster draws its current from the host bus, so the lead needs no external power adapter. Tinned oxygen-free copper conductors carry the signal pairs and limit resistive loss over the full length.

Double shielding combines an aluminium foil wrap with a braided metal layer to hold off EMI and RFI from nearby power supplies. A PVC and ABS overmould anchors each connector against pull strain. The 10 m span reaches printers, scanners, card readers and cameras across a room without an intermediate hub.

Plug-and-play operation needs no driver on Windows, macOS or Linux. Hot-swap support lets technicians move the attached device between hosts without rebooting either end. The cable suits retail counters, workshop benches and reception desks where the PC sits away from the device. A 5.5 mm outer diameter fits standard cable management trunking.

Key Features

• FE1.1s Booster Chip
  The embedded stage regenerates the USB data pair so signal integrity holds across the full 10 m length.

• USB 2.0 Hi-Speed Throughput
  The lead sustains the 480 Mbps rate and falls back to USB 1.1 devices without configuration.

• Bus-Powered Operation
  The booster draws current from the host port and needs no wall adapter or inline injector.

• Shielding and Conductor Build

  • Tinned oxygen-free copper conductors reduce resistive loss.
  • Aluminium foil plus braided shield suppress EMI and RFI ingress.
  • PVC and ABS overmould protects the solder joints at each plug.

• USB-A Male to Female Ends
  The male plug seats in the host port and the female socket accepts the peripheral cable.

• Driver-Free Installation
  The assembly enumerates on Windows, macOS and Linux without vendor software.

• Hot-Swap Support
  Technicians can move the attached device between hosts without powering down either end.

Specifications

What’s in the Box

• 10 m active USB 2.0 extension lead, A male to A female

• Protective caps on both connectors

Why Choose the US121 Lead

• The FE1.1s stage restores eye height that a passive lead loses beyond five metres.

• Bus power removes the need for a socket at the far end of a counter or bench.

• Foil and braid shielding keep the link stable beside monitors and switching power supplies.

• Oxygen-free copper conductors hold voltage drop low enough for bus-powered peripherals.

• The 10 m length reaches across a room without adding an intermediate hub or extender.
