Toshiba MR-3032 Reversing Automatic Document Feeder 50-Sheet A5-A3 RADF

Reversing Feeder Unit for e-STUDIO Copiers

The Toshiba MR-3032 RADF is a reversing automatic document feeder for e-STUDIO 2323AM, 2523A, 2523AM, 2823AM, 2329A and 2829A multifunction copiers. It holds 50 sheets of A4 at 80 gsm and accepts originals from A5 to A3. The reversing path turns each page for duplex copying without operator intervention.

Paper weight support spans 50 to 104 g/m², which covers thin bond, standard copy paper and light card stock. Feeding speed runs approximately 37 to 111 mm/s across the supported sizes. The unit draws about 40 W from the copier chassis and needs no separate power outlet or adapter.

The assembly measures 570 x 445 x 88 mm and weighs roughly 4.5 kg. A status lamp on the cover reports feed condition, jam state and job completion. Supported original formats include A3, A4, A4-R, A5-R, B4, B5, LD, LG and LT. The feeder mounts on the platen hinge points and connects to the copier interface.

Service technicians replace the unit when pickup rollers wear or the reverse path develops misfeeds. The complete assembly removes as one part, so a swap needs no roller-by-roller rebuild. Site teams should power the copier down before unplugging the feeder harness.

Key Features

• 50-Sheet Input Tray
  The tray holds a full A4 stack at 80 gsm for unattended batch runs.

• Reversing Duplex Path
  Pages turn inside the feeder so two-sided originals copy in one pass.

• Wide Original Range
  The feed path accepts A5 through A3 sheets, including A4-R and A5-R orientation.

• Paper Weight Envelope

  • Minimum stock weight of 50 g/m².
  • Maximum stock weight of 104 g/m².
  • Handles bond, copy paper and light card.

• Status Indicator Lamp
  An LED on the cover shows feed condition without opening the unit.

• Chassis-Powered Operation
  The feeder draws approximately 40 W from the copier and needs no mains feed.

• Single-Part Replacement
  The assembly swaps as one unit instead of a roller-by-roller rebuild.

Specifications

What’s in the Box

• Feeder assembly unit

• Mounting hardware

• Installation notes

Why Choose the MR-3032 Feeder

• The 50-sheet tray cuts operator trips on multi-page copy and scan jobs.

• The reversing path processes two-sided originals without manual page flipping.

• A5 to A3 coverage removes the need for a second platen-fed workflow on large layouts.

• The assembly draws power from the copier, so no extra cabling runs to a wall socket.

• A single-part swap restores a worn feeder without a staged roller rebuild.
