Toshiba 6LK69617000 Transfer Roller Assembly ASYB-CH-TR-H41X_N

Secondary transfer roller for e-STUDIO mono copiers

The Toshiba 6LK69617000 transfer roller is the secondary transfer assembly for the e-STUDIO 2018A through 5018A monochrome range. It carries the Toshiba assembly code ASYB-CH-TR-H41X_N and seats in the transfer unit opposite the drum. The roller applies bias during transfer and moves the toner image from the photoconductor onto the sheet.

The assembly includes the roller, shaft and end bushes. Cross-reference codes include 6LK69610000 and FC556TR2. The conductive roller surface holds a uniform charge across the page width. End bushes locate the shaft in the transfer frame and maintain the correct nip against the drum.

Compatible chassis cover the e-STUDIO 2018A, 2518A, 3018A, 3018AG, 3518A, 3518AG, 4518A, 4518AG, 5018A, 2008A, 2508A, 3008A, 3508A, 4508A and 5008A. The same assembly serves the 3018AG and 4518AG variants. Confirm the model code against the parts list before ordering, because Toshiba uses different transfer assemblies across product families.

Worn transfer rollers cause light transfer, background scatter or repeating marks down the page. A contaminated roller surface shows as a faint ghost of the previous image. Replacing the assembly restores transfer efficiency without swapping the complete transfer unit. Inspect the drum and the transfer guide at the same time, since a scored drum damages a new roller.

Fit the assembly with the transfer unit removed from the machine. Clean toner residue from the frame before seating the new roller, and avoid touching the conductive surface with bare fingers. Confirm that the end bushes sit square in their slots and that the roller turns freely. Run a test print and inspect for transfer faults before returning the machine to service.

Key Features

• Secondary transfer roller assembly
  The unit transfers the toner image from the drum to the sheet under applied bias.

• Complete assembly with shaft and bushes

  • Roller, shaft and end bushes ship as one unit
  • Conductive surface holds uniform charge across the page
  • Bushes set the correct nip against the drum

• OEM part identification
  The assembly carries Toshiba code 6LK69617000 and description ASYB-CH-TR-H41X_N.

• Cross-reference support
  The part cross-references 6LK69610000 and FC556TR2 for stock checks.

• Broad model coverage
  The roller fits 2018A, 2518A, 3018A, 3518A, 4518A, 5018A, 2008A, 2508A, 3008A, 3508A, 4508A and 5008A chassis.

• Single-unit packaging
  The assembly ships individually for service stock and single-machine repairs.

Specifications

What’s in the Box

• One transfer roller assembly with shaft and end bushes

Why Choose This Transfer Assembly

• The complete assembly restores transfer efficiency without replacing the full transfer unit.

• OEM roller conductivity keeps bias uniform and prevents light transfer or background scatter.

• One part covers a wide range of e-STUDIO mono chassis, which simplifies spare-stock holding.

• Pre-fitted shaft and bushes shorten field replacement time.

• Cross-referenced codes simplify identification against supplier catalogues.
