Toshiba 6LJ76871000 GEAR-10S20-DRV-FUS Fuser Drive Gear

Fuser drive gear for e-STUDIO mono chassis

The Toshiba 6LJ76871000 is the fuser drive gear used in several Toshiba e-STUDIO monochrome copiers. It transfers torque from the main drive train to the fuser roller assembly. The part carries the designation GEAR-10S20-DRV-FUS-H24X in Toshiba service documentation.

The moulded gear seats on the fuser drive shaft and meshes with the adjacent drive gears. A keyed bore aligns the gear to the shaft flat, which prevents rotational slip under load. Tooth profile and module match the original part, so the drive train keeps its designed backlash and timing.

Compatible chassis include the e-STUDIO 2006, 2306, 2506, 2007, 2307, 2507, 2303, 2303A, 2309, 2505, 2505F, 2505H, 2802A, 2802AM, 2802AF, 2822 and 0906. The part cross-references 6LJ76819000. Confirm the machine model before ordering, because Toshiba uses different fuser drive gears across product families.

Worn fuser drive gears cause uneven fuser roller speed, which appears as repeating marks, blurred fusion or paper transport faults. A cracked or stripped gear can stop the fuser from turning and trigger a jam or fuser error. Replacing the gear restores drive continuity without swapping the complete fuser unit.

Fit the gear with the fuser unit removed from the machine. Clean old grease and toner from the shaft, then seat the new gear fully on the flat. Check that the gear meshes freely with the idler before refitting the fuser. Run a test print and inspect for repeat defects after the repair.

Inspect the mating gears during the same service. Wear on one gear usually spreads to the idler and the drive coupling, and a new gear running against a worn mate wears quickly. Replace any gear with rounded teeth, cracks at the hub or a polished bore. Keep spare gears in the original packaging until fitting.

The gear is a field-serviceable item. Access requires removal of the fuser unit and the rear drive cover on most chassis. Allow the fuser to cool before handling, because the roller reaches operating temperature above 180 °C. Follow the service manual torque values for the drive cover screws.

Order the part by the Toshiba code rather than by description alone. The same GEAR-10S20-DRV-FUS designation appears in parts lists for several models, and stock descriptions vary between suppliers. Verify the code against the machine parts catalogue before dispatch.

The gear ships as a single unit. It needs no lubrication out of the box beyond the small amount of grease specified for the shaft. Excessive grease attracts toner and dust, which accelerates wear on the tooth flanks.

Key Features

• Fuser drive gear
  The part transfers drive torque to the fuser roller assembly on listed e-STUDIO chassis.

• Keyed bore alignment

  • Bore key seats on the shaft flat to stop rotational slip
  • Matched tooth module keeps drive train backlash within specification
  • Moulded hub resists cracking at the shaft interface

• Multi-model compatibility
  The gear fits e-STUDIO 2006, 2306, 2506, 2007, 2307, 2507, 2303, 2303A, 2309, 2505, 2505F, 2505H, 2802A, 2802AM, 2802AF, 2822 and 0906.

• Cross-reference 6LJ76819000
  The part cross-references the alternate Toshiba code for stock identification.

• Field-serviceable fit
  The gear installs with the fuser unit removed and needs no machining or modification.

• Single-unit packaging
  Each gear ships individually for service stock and single-machine repairs.

Specifications

What’s in the Box

• One fuser drive gear

Why Choose This Fuser Gear

• The replacement gear restores fuser rotation without replacing the complete fuser unit.

• Matched tooth profile keeps the drive train timing and backlash within specification.

• One part covers a wide range of e-STUDIO monochrome chassis.

• Single-unit packaging suits field engineers who carry a small parts kit.

• Cross-referenced part codes simplify stock checks and ordering.
