Toshiba 6LJ76810000 Gear 10S40-10S31 Main Drive for e-Studio Copiers

Main Drive Gear for e-Studio Mono Copiers

The Toshiba 6LJ76810000 gear is the GEAR-10S40-10S31 drive component used in the main drive unit of Toshiba e-Studio mono copiers. It meshes with the mating pinion on the drive shaft and transfers motor torque into the process assembly. Toshiba lists the part for the 2006, 2306, 2506, 2007, 2307 and 2507 chassis.

The gear carries Toshiba’s 10S40-10S31 designation, which identifies the tooth profile and shaft interface used in this drive train. It seats on the drive shaft inside the main reducer housing. Two gear faces run against the adjacent pinion, so the moulded teeth carry continuous load through every copy cycle.

Fit the part during main drive service or when the original shows chipped or polished teeth. Remove the drive unit cover, release the retaining clip and slide the gear off its shaft. Check the mating gear for matching wear before reassembly. The part also fits e-Studio 2303A, 2309A, 2809A, 2303AM, 2803AM, 2505, 2505F, 2505H and 2802A/AM/AF models.

Key Features

• Main Drive Gear
  The gear transfers motor torque into the e-Studio process assembly through the main reducer train.

• GEAR-10S40-10S31 Designation

  • Toshiba codes the tooth profile and shaft interface in the part description.
  • The code simplifies matching against the service parts catalogue.

• Shaft-Mounted Fit
  The gear slides onto the drive shaft inside the reducer housing and locks with the retaining clip.

• Wide Chassis Coverage

  • Fits e-Studio 2006, 2306, 2506, 2007, 2307 and 2507.
  • Fits e-Studio 2505, 2505F and 2505H.
  • Fits e-Studio 2303A, 2309A, 2809A, 2303AM and 2803AM.
  • Fits e-Studio 2802A, 2802AM and 2802AF.

• Wear Diagnosis
  Chipped or polished teeth produce clicking, drive noise or a repeating pitch line on the copy.

• Service Replacement
  The gear replaces a worn drive component without changing the reducer housing or motor.

• Single-Unit Supply
  The pack holds one gear for one drive train repair.

Specifications

What’s in the Box

• One 6LJ76810000 drive gear

Why Choose This Toshiba Drive Gear

• The main drive gear restores torque transfer when the original teeth wear or chip.

• The 6LJ76810000 number matches the Toshiba service parts catalogue for direct ordering.

• The reducer gear fits several e-Studio chassis, which simplifies spare-parts stock.

• A shaft-mounted design removes the need for press tools during replacement.

• The single-unit pack covers one drive repair without surplus inventory.

• Inspecting the mating pinion at the same time prevents repeat failures after reassembly.
