Toshiba 6LH58563000 2nd Transfer Roller for DP-2090/2520/3000/3570/4570

Replacement Transfer Roller for Toshiba DP Series

The Toshiba 2nd transfer roller replaces part 6LH58563000 in the second transfer position of the DP series paper path. It presses the sheet against the drum and carries the transfer bias that moves toner onto the paper.

The roller uses a conductive rubber sleeve bonded to a steel shaft. Sealed bearings sit at each end and locate the assembly in the transfer unit journals. The shaft ends are machined to the original diameter so the retaining clips hold the roller square to the paper path. The rubber durometer and surface finish match the OEM part, which keeps transfer current inside the printer’s specified range.

A worn roller causes light prints, background fog or repeated marks down the page. The damaged surface loses contact pressure and transfer efficiency drops. Streaking that repeats at the roller circumference points to a damaged sleeve. Inspect the old roller for flat spots, cuts or toner fused to the surface. Fitting a new assembly restores the bias path and clears those print defects.

Installation requires removing the transfer unit and releasing the old roller from its retaining clips. The new shaft seats in the same journals, and the clips lock it in place. Power down the printer and allow the fuser to cool before opening the transfer unit. Static discharge can damage the controller, so ground yourself before touching the assembly. Handle the rubber with clean gloves and keep oils and solvents off the surface.

Key Features

• OEM Toshiba Part 6LH58563000
  The assembly carries the Toshiba part number and matches the original transfer roller dimensions.

• Conductive Rubber Sleeve
  The sleeve carries transfer bias evenly across the paper width.

• Steel Shaft with Sealed Bearings
  The shaft locates in the transfer unit journals and the bearings run without lubrication.

• Direct Second Transfer Fit
  The roller drops into the second transfer position without modification.

• DP Series Compatibility
  The part fits DP-2090, DP-2520, DP-3000, DP-3570 and DP-4570 models.

• Complete Assembly
  The roller ships with shaft and bearings fitted, so no parts transfer is needed.

• Restores Print Quality
  Replacing a worn roller removes light print, fog and repeated marks.

Specifications

What’s in the Box

• Toshiba 6LH58563000 2nd transfer roller assembly

Why Choose the OEM Roller

• Original dimensions keep the transfer unit aligned to the drum.

• The conductive sleeve holds bias across the full paper width.

• Sealed bearings resist toner dust in the transfer housing.

• The complete assembly avoids bearing transfer and alignment errors.

• Correct durometer maintains contact pressure over the roller life.

• One part number covers five DP models in a mixed fleet.
