Powermax 13A 1 Gang Metal-Clad Switched Socket Single Pole BS 1363-2
Original price was: KSh 700.00.KSh 600.00Current price is: KSh 600.00. ex VAT
Powermax 13A 1 Gang Metal-Clad Switched Socket Single Pole BS 1363-2
| Gang count | 1 |
| Current rating | 13A |
| Voltage rating | 230V AC |
| Switching | Single pole, switched |
| Earth terminals | Dual |
| Terminal capacity | 3 x 2.5mm² or 2 x 4.0mm² |
| Plate size | 86 x 86mm square edge |
| Minimum box depth | 25mm |
| Housing | Metal-clad |
| Standard | BS 1363-2 |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Metal-Clad Switched Outlet
The Powermax 13A socket is a single-gang switched outlet built into a metal-clad housing for surface or conduit-box mounting. It carries a 230V 13A single-pole rating and dual earth terminals. The square-edge plate suits domestic, commercial and light industrial wiring.
Angled in-line terminals with captive screws hold 2.5mm² and 4.0mm² conductors. A single-pole switch breaks the live conductor only, which suits ring and radial circuits. The metal enclosure shields the terminal block from impact and adds mechanical protection where plastic plates would crack.
The socket follows BS 1363-2 for 13A fused plugs and shuttered contacts. Two earth terminals allow loop-in and loop-out wiring on the same plate. The switch mechanism uses a rocker rated for repeated operation. Fixing screws and a earth fly lead ship with the unit.
Installation requires a 25mm minimum back box depth, and the metal-clad body accepts 20mm conduit entries. The plate measures 86mm square and aligns with standard square-edge accessory ranges. Terminal capacity covers three 2.5mm² conductors or two 4.0mm² conductors per terminal.
Key Features
Single-Pole 13A Switching
The rocker breaks the live conductor at 13A and 230V for standard ring and radial circuits.Metal-Clad Enclosure
The steel housing protects the terminal block and plate against impact in commercial and workshop areas.Dual Earth Terminals
- Two earth points support loop-in and loop-out wiring
- Earth fly lead included for metal-box bonding
- Captive screws speed termination
Angled In-Line Terminals
The terminal block accepts 2.5mm² and 4.0mm² conductors at an angle that clears the box wall.BS 1363-2 Compliance
The socket meets the British standard for 13A shuttered outlets and fused plugs.Square-Edge Plate
The 86mm square plate fits standard square-edge accessory boxes and conduit systems.
Specifications
| Feature | Specification |
|---|---|
| Gang count | 1 |
| Current rating | 13A |
| Voltage rating | 230V AC |
| Switching | Single pole, switched |
| Earth terminals | Dual |
| Terminal type | Angled in-line with captive screws |
| Terminal capacity | 3 x 2.5mm² or 2 x 4.0mm² |
| Plate size | 86 x 86mm square edge |
| Minimum box depth | 25mm |
| Housing | Metal-clad |
| Standard | BS 1363-2 |
| Fixings | Screws and earth fly lead included |
What’s in the Box
Powermax 13A 1 gang metal-clad switched socket
Fixing screws
Earth fly lead
Why Choose This Switched Outlet
The metal housing survives knocks in workshops, plant rooms and service corridors.
Dual earth points remove the need for a separate earth block on looped circuits.
Captive screws stay with the plate during installation and servicing.
The 13A rating covers standard UK-pattern plugs and fused appliance leads.
BS 1363-2 compliance supports electrical certification and inspection records.
The 86mm square plate aligns with common conduit box and trunking systems.
