OEM SC-SC APC 10m OM3 Multi-mode Fiber Cable
WhatsApp for availability
OEM SC-SC APC 10m OM3 Fiber Patch Cable
| Feature | Specification |
|---|---|
| Connector Type | SC to SC (APC) |
| Fiber Grade | OM3 Multi-mode |
| Length | 10 Meters |
| Jacket | LSZH |
| Bandwidth | 10Gbps @ 300m |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
OEM SC-SC OM3 Patch Cord
The OEM SC-SC APC OM3 optical fiber assembly provides high-bandwidth data transmission for enterprise-level networking environments. This 10-meter patch cable utilizes laser-optimized multi-mode glass to support 10 Gigabit Ethernet applications up to 300 meters. The integration of Angled Physical Contact (APC) ferrules on a multi-mode core addresses specialized return loss requirements in sensitive optical circuits. Network engineers deploy this solution to ensure stable signal propagation across high-density distribution frames. This specific configuration bridges the gap between standard multi-mode capacity and high-precision connector geometry.
Key Features
Angled Physical Contact Ferrules
The 8-degree angled polish on the SC connectors redirects back reflections into the cladding to minimize return loss.Laser-Optimized Multi-mode Core
- 50/125 micrometer core-to-cladding diameter ratio.
- 2000 MHz·km Effective Modal Bandwidth at 850nm.
- Full compatibility with VCSEL laser sources and legacy LED systems.
Low Smoke Zero Halogen Jacket
The LSZH outer sheath restricts the emission of toxic smoke and corrosive gases during thermal decomposition.Standardized SC Housing
- Push-pull locking mechanism ensures secure coupling in high-vibration environments.
- Zirconia ceramic ferrules maintain precise axial alignment for consistent insertion loss.
Specifications
| Feature | Specification |
|---|---|
| Fiber Type | OM3 Multi-mode (Laser Optimized) |
| Connector Type | SC to SC |
| Polish Type | APC (Angled Physical Contact) |
| Cable Length | 10 Meters |
| Core/Cladding | 50/125 µm |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 60 dB |
| Operating Wavelength | 850 nm / 1300 nm |
| Jacket Diameter | 2.0 mm |
What’s in the Box
1 x 10m SC-SC APC OM3 Multi-mode Fiber Patch Cable
Factory Test Documentation
Protective Dust Caps
Why Choose OEM SC-SC OM3 Patch Cord
The 10-meter reach facilitates inter-cabinet connectivity within large data center footprints.
APC polishing significantly improves return loss compared to standard UPC multi-mode variants. Consequently, this reduces bit error rates in high-speed transceivers.
Individual testing ensures every cable meets strict attenuation standards before deployment. However, installers must verify equipment compatibility with angled multi-mode connectors.
The LSZH jacket meets stringent fire safety regulations for indoor riser and plenum-adjacent installations. Therefore, it satisfies building code requirements for commercial infrastructure.
Standardized SC connectors offer a robust form factor that resists lateral pull forces better than smaller LC alternatives. Additionally, the ceramic ferrules provide long-term durability over multiple mating cycles.
