Nexa CAT6 Outdoor UTP Full Copper 305M Cable
WhatsApp for availability
Nexa CAT6 Outdoor UTP Full Copper 305M Cable
| Feature | Details |
|---|---|
| Conductor | 23 AWG Solid Bare Copper |
| Jacket | UV-Resistant PE (Outdoor) |
| Length | 305M Pull Box |
| Standard | Category 6 UTP |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
Nexa CAT6 Outdoor UTP
The Nexa CAT6 Outdoor Cable provides high-performance data transmission for external networking environments. This bulk Ethernet solution utilizes solid bare copper conductors. It supports bandwidth frequencies up to 250 MHz. The design meets TIA/EIA 568-C.2 standards for Category 6 infrastructure.
The internal architecture features four unshielded twisted pairs. A central cross-separator isolates these pairs to minimize internal crosstalk. This physical separation ensures signal clarity during high-speed data transfers. The 23 AWG conductor size facilitates efficient Power over Ethernet (PoE) delivery. Solid copper offers lower DC resistance compared to aluminum alternatives. This characteristic prevents excessive heat buildup in high-density installations.
External protection involves a rugged Polyethylene (PE) jacket. This material resists ultraviolet radiation and moisture ingress. It maintains structural integrity under fluctuating temperature conditions. The high-density polyethylene insulation on individual wires prevents signal leakage. This Nexa external cabling solution arrives in a 305-meter pull box for easy deployment. Sequential meter markings on the jacket simplify length calculations during installation.
Network engineers utilize this cabling for outdoor access points and surveillance cameras. It maintains 1000BASE-T performance over standard distances. The absence of shielding makes termination simpler in non-EMI heavy environments. Each coil undergoes testing to ensure compliance with gigabit networking requirements. The internal spline maintains the precise twist ratio of the pairs. This prevents mechanical deformation during the pulling process.
Key Features
UV-Resistant PE Jacket
The outer layer consists of high-density polyethylene to withstand direct sunlight and moisture.Solid Bare Copper Conductors
- 23 AWG 100% copper wire ensures maximum conductivity.
- Full copper construction reduces signal attenuation over long distances.
Integrated Cross-Separator
An internal HDPE spline maintains pair geometry to reduce near-end crosstalk (NEXT).
Specifications
| Feature | Specification |
|---|---|
| Conductor Material | 100% Solid Bare Copper |
| Wire Gauge | 23 AWG |
| Cable Type | UTP (Unshielded Twisted Pair) |
| Jacket Material | PE (Polyethylene) – UV Resistant |
| Bandwidth Support | Up to 250 MHz |
| Transmission Speed | 10/100/1000 Mbps |
| Length | 305 Meters (1000 Feet) |
| Insulation Material | HDPE |
What’s in the Box
1 x 305M Nexa Category 6 Outdoor UTP Full Copper Cable Pull Box
Why Choose Nexa CAT6 Outdoor UTP
Solid copper construction supports long-distance PoE applications without voltage drop.
Outdoor-rated PE jacket prevents cracking and degradation from environmental exposure.
Internal spline ensures consistent performance by maintaining twisted pair integrity.
Meter markings allow precise measurement and reduce cable wastage during installation.
Josphat Mwangi (verified owner) –
Finally found genuine full copper cable in Nairobi. Most shops in town sell CCA but label it as copper which fails after a few months. This Nexa roll is heavy and the speeds are very consistent even for the 80-meter runs I did for our office extension. The outdoor sheath feels like it can handle the Nairobi sun and the heavy rains without cracking. Good value for money.
Faith Achieng (verified owner) –
Good quality cable and the delivery to Westlands was very fast. Using it for my home outdoor APs and it’s working well so far.
Kevin Omondi (verified owner) –
The Nexa CAT6 is decent for the price. The internal wires are pure copper as advertised, which is great for POE cameras because there’s no voltage drop. Only small issue is the outer jacket is a bit stiff to strip if you don’t have a proper stripper tool, but that’s expected for outdoor grade. Much better than the generic brands I’ve used before.
