M61 Hydraulic Door Closer 85 kg, EN4 Overhead Closer with Adjustable Speed

Rack-and-Pinion Overhead Closer

The M61 door closer is a surface-mounted hydraulic unit for single-leaf doors up to 85 kg and 1200 mm wide. A rack-and-pinion mechanism drives the closing cycle through a spring and oil chamber. The die-cast aluminium body carries a painted finish that suits steel, timber and glass doors.

Two independent valves set the closing speed from 180° to 15° and the latching speed from 15° to 0°. The arm sweeps a maximum opening angle of 180°. A non-handed body serves left and right swing doors from one stock item. Fixing holes follow the standard 19 mm and 38 mm pattern.

The closer mounts on the pull side or push side with the supplied arm and wood screws. Operating temperature spans -20 °C to +50 °C. The non-hold-open design returns the leaf after every pass, which keeps fire doors and access-controlled openings shut. Service life reaches 500,000 cycles under normal duty.

Key Features

• Twin Hydraulic Speed Valves
  Separate screws trim the sweep and latch phases so the leaf lands without slamming.

• Rack-and-Pinion Drive
  The steel rack and pinion convert arm rotation into a controlled piston stroke.

• Adjustable Closing Force

  • Spring preload screw spans the EN4 setting
  • Suits leaves from 60 kg to 85 kg
  • Compensates for wider openings and higher wind pressure

• Non-Handed Body
  One chassis installs on left-hand and right-hand doors without a handed variant.

• Non-Hold-Open Action
  The closer returns the door after each pass, which suits fire doors and controlled entries.

• Standard Fixing Pattern
  The 19 mm and 38 mm hole centres match common door preparation templates.

Specifications

What’s in the Box

• 1 x M61 hydraulic door closer body

• 1 x adjustable steel arm

• Fixing screws and sleeve anchors

• Installation template and instructions

Why Choose This Overhead Unit

• Two valve screws let a technician tune the sweep and latch without swapping parts.

• The EN4 spring range covers most commercial single-leaf doors in one model.

• Non-handed stock lowers the number of variants a store room has to carry.

• Rack-and-pinion construction holds timing through high-traffic entrances.

• The painted alloy body resists corrosion in covered external doorways.
