Lightwave LW-ODF-24LC-LOAD-RM 24-Port LC Fiber Patch Panel
Limited Stock
Lightwave LW-ODF-24LC-LOAD-RM 24-Port LC Fiber Patch Panel
| Feature | Specification |
|---|---|
| Port Count | 24 LC Ports |
| Form Factor | 1U 19″ Rack Mount |
| Material | Cold-rolled Steel |
| Includes | Splice Tray & Adapters |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Lightwave LW-ODF-24LC-LOAD-RM
The Lightwave 24-Port LC Panel provides high-density optical fiber termination within a standard 19-inch rack environment. This unit integrates cable management and fusion splicing capabilities into a single 1U chassis. The front panel houses 24 LC ports using high-precision ceramic alignment sleeves. These components ensure consistent low-loss connections for high-speed data networks. The chassis utilizes 1.2mm cold-rolled steel for maximum structural integrity. This loaded configuration includes all necessary adapters to streamline deployment in telecommunications rooms. The powder-coated finish provides resistance against corrosion and mechanical wear.
The sliding tray mechanism allows for full extension of the internal work area. This feature enables technicians to perform splicing or cable routing without removing adjacent equipment. Multiple cable entry points on the rear panel accommodate different trunk cable diameters. Rubber grommets at these entries maintain a clean internal environment by blocking dust. The internal splice tray organizes up to 24 fusion splices in a secure, stacked arrangement. Clear plastic covers on the tray protect the splices while allowing for visual inspection.
Integrated fiber management hoops maintain the 30mm minimum bend radius throughout the enclosure. This protection is vital for maintaining signal quality in single-mode fiber runs. The 1U height ensures efficient use of vertical rack space in high-density data centers. Each LC port includes a dedicated dust cap to protect the internal ceramic sleeve. The front panel features clear labeling strips for port identification. This helps prevent connection errors during high-pressure maintenance windows.
The earthing kit provides a reliable path for electrical grounding. This protects the metallic chassis from static buildup and potential surges. The mounting brackets are adjustable to fit various rack depths. Additionally, this versatility makes the unit compatible with most standard networking cabinets. The unit undergoes rigorous testing to meet TIA/EIA standards for optical performance. Technicians can rely on the robust construction for long-term infrastructure stability.
Key Features
Chassis Construction
The 1.2mm cold-rolled steel frame provides a rigid housing for sensitive optical components.Cable Management
Internal routing hoops maintain a 30mm minimum bend radius to prevent signal attenuation.Splicing Integration
- Supports 24 fusion splices
- Includes transparent tray cover
- Stackable tray design
Port Density
The 1U design accommodates 24 LC ports using high-precision ceramic alignment sleeves.Environmental Protection
Rear cable entries feature rubber grommets to prevent dust ingress and protect fiber jackets.
Specifications
| Feature | Specification |
|---|---|
| Model | LW-ODF-24LC-LOAD-RM |
| Fiber Capacity | 24 Fibers |
| Adapter Type | LC (Ceramic Sleeve) |
| Rack Units | 1U |
| Material | 1.2mm Cold-rolled Steel |
| Mounting | 19-inch Rack Mount |
| Dimensions | 482mm x 200mm x 44mm |
| Operating Temp | -40°C to +80°C |
What’s in the Box
1 x Lightwave 24-Port ODF Chassis
24 x LC Fiber Adapters (Pre-installed)
1 x 24-Core Splice Tray
1 x Earthing Kit and Mounting Hardware
Why Choose Lightwave LW-ODF-24LC-LOAD-RM
High-precision ceramic sleeves ensure low insertion loss for reliable data transmission.
The sliding drawer mechanism facilitates rapid access for splicing and maintenance tasks.
Heavy-duty steel construction maintains structural alignment even under heavy cable loads.
Josphat Kamau (verified owner) –
The unit is functional and the 24-port density is great for saving rack space. However, the mounting ears were a bit of a tight squeeze in our older cabinet, had to adjust the rails slightly to get it flush. Once in, it’s solid and the fiber connections are stable. Good value for money for local networking projects if you are on a budget.
Evans Kiprono (verified owner) –
We used this Lightwave 24-port panel for a server room upgrade in Upper Hill. The LC adapters are well-aligned and the sliding tray makes it very easy to manage the splicing inside. It’s a solid 1U unit that fits perfectly in our standard rack. Definitely better quality than the generic ones we’ve seen before in the CBD.
Mercy Wanjiru (verified owner) –
The LW-ODF-24LC is quite decent for the price. Came fully loaded with the LC duplex adapters so we didn’t have to source them separately, which saved us time on the installation. The powder-coat finish is good, no sharp edges to cut the patch cords. Just wish the labeling strip was a bit larger for easier marking, but otherwise, it’s working well for our fiber backbone.
Brian Otieno (verified owner) –
Good fiber patch panel. Delivered to our office in Westlands very quickly. Build is sturdy and the ports are tight.
