HP EliteBook 830 G5 G6 13.3 Inch FHD Touch Screen LCD Assembly 40-Pin

Replacement Display Assembly for EliteBook 830 Series

The HP 830 G5 touch screen assembly restores touch input and video output on compatible 13.3-inch notebooks. This complete hinge-up unit ships as a single part with the LCD panel, touch digitizer and bezel already bonded. HP fits the assembly to both the G5 and G6 generations of the EliteBook 830 chassis.

The panel resolves 1920 x 1080 pixels on a 13.3-inch diagonal with LED backlighting. A 40-pin eDP connector exits at the bottom right of the panel and mates with the factory display cable. The touch layer uses in-cell on-cell technology, which integrates the digitizer into the LCD cell rather than adding a separate glass layer.

Brightness ratings fall between 250 and 300 nits, and the refresh rate holds at 60 Hz. The unit weighs approximately 350 g. A scratch-resistant coating covers the touch surface. The narrow frame matches the original bezel dimensions, so the assembly seats into the lid without modification. The package does not include hinges, display cable or screws.

Key Features

• Complete Hinge-Up Touch Assembly
  The part ships with the LCD, digitizer and bezel bonded as one unit, which removes separate glass alignment during repair.

• Dual-Generation Compatibility

  • Fits HP EliteBook 830 G5 chassis
  • Fits HP EliteBook 830 G6 chassis
  • 40-pin eDP connector matches the factory display cable

• Full HD In-Cell Touch Panel
  The 1920 x 1080 panel integrates the touch sensor into the LCD cell and supports multi-touch gestures.

• Narrow Frame Geometry
  The bezel dimensions match the original narrow frame, so the lid closes flush after installation.

• 60 Hz Refresh with LED Backlight
  The diode backlight runs at 60 Hz and reaches 250 to 300 nits for indoor office use.

• Scratch-Resistant Surface
  A hard coating covers the touch glass and resists abrasion from daily stylus and finger contact.

• Wide Viewing Angles
  The panel maintains colour consistency at 178-degree horizontal and vertical viewing angles.

• Operating Temperature Range
  The assembly functions between 0°C and 50°C and stores safely from -20°C to 60°C.

Specifications

What’s in the Box

• 13.3-inch FHD touch screen LCD assembly

• Protective packaging

Why Choose This Display Assembly

• The bonded hinge-up unit cuts repair time by removing the need to separate glass from panel.

• Dual G5 and G6 compatibility lets service teams stock one part number for both generations.

• The 40-pin connector matches the factory cable, so no adapter or pin rework is required.

• In-cell touch construction keeps the assembly thin and preserves the original lid profile.

• The scratch-resistant coating extends service life in shared-device deployments.

• Wide viewing angles support customer-facing kiosk and presentation use cases.
