EVI EP-UPSP11-MBP 2U Maintenance Bypass PDU 6-10kVA

EVI EP-UPSP11-MBP Maintenance Module

The EVI Maintenance Bypass PDU integrates directly into mission-critical power architectures to ensure zero downtime. This 2U rack-mounted component allows technicians to bypass the UPS electronics completely. It supports high-capacity power protection units between 6kVA and 10kVA. The internal switching mechanism maintains a continuous circuit to the load during transitions.

The front-facing manual switch provides clear operational states. Operators can move from UPS mode to Bypass mode without dropping the connected equipment. This functionality is essential for routine battery maintenance or emergency UPS replacement. The unit features an integrated circuit breaker for overcurrent protection. This ensures the safety of downstream hardware when the UPS is out of the circuit.

The chassis uses a standard 19-inch width for easy rack integration. Its 2U height optimizes vertical space in server cabinets. Heavy-duty terminal blocks accommodate the high-gauge cabling required for 10kVA electrical loads. The metal housing provides electromagnetic shielding and physical durability. It withstands the heat generated by continuous high-current distribution. The terminal block arrangement supports various wire gauges to meet local electrical codes. This flexibility allows for integration into diverse power distribution environments.

Maintenance personnel use this module to isolate the UPS unit safely. It eliminates the need to shut down servers for power supply servicing. The design prioritizes electrical safety and mechanical reliability. This power distribution tool simplifies the complex task of managing high-power UPS systems in dense IT environments. It serves as a permanent wiring hub for the UPS input and output. The manual switch includes a protective guard to prevent accidental actuation during normal operation. This safety feature is vital in high-traffic server rooms where physical contact with the rack is common.

The EP-UPSP11-MBP handles single-phase input and output. It manages the high amperage associated with large-scale network infrastructure. The layout allows for easy access to wiring terminals. This speeds up the initial installation process. It also facilitates faster troubleshooting of power distribution issues. The module operates reliably within standard data center temperature and humidity ranges. This ensures long-term performance in active equipment rooms. The switch mechanism is tested for high-cycle reliability. Consequently, this ensures smooth operation over the lifespan of the data center infrastructure.

Key Features

• Make-Before-Break Switching
  The internal contact design ensures the load never loses power during manual transitions.

• Overcurrent Protection

  • Integrated industrial-grade circuit breaker
  • Protects downstream equipment during bypass mode

• Rackmount Integration
  The 2U form factor fits standard 19-inch server racks with included mounting hardware.

Specifications

What’s in the Box

• EVI EP-UPSP11-MBP Maintenance Bypass Module

• Rackmount Brackets and Screws

• Technical Installation Manual

Why Choose EVI EP-UPSP11-MBP

• Reduces Mean Time To Repair (MTTR) by allowing live UPS swaps.

• Provides a centralized wiring hub for high-capacity 10kVA power systems.

• Ensures electrical isolation for technician safety during UPS maintenance.

• Eliminates the need for scheduled downtime during battery replacements.
