Datalogic 94A150062 Single Slot Desk Mount Dock with Spare Battery Charging Slot

Charging Cradle for Skorpio Mobile Computers

The Datalogic 94A150062 dock is a single-slot desk mount cradle that charges a Skorpio X3 or X4 terminal and a spare battery at the same time. It provides a high-retention USB-R Type B client port and an RS232 serial port for host communication. The package includes a power supply with regional plugs and a USB cable.

The cradle accepts the mobile computer in the front slot and a spare battery in the rear charging bay. Both charging paths run from the supplied external power adapter, so the dock does not draw current from the host USB bus. The high-retention USB-R connector keeps the cable seated when the terminal is inserted and removed repeatedly. The RS232 port supports legacy serial host connections at standard baud rates.

The desk mount base measures 197 x 111 x 150 mm and weighs 0.706 kg with packaging. A weighted footprint and rubber feet keep the cradle stable during one-handed docking. The housing uses durable ABS plastic that resists scuffs in retail, warehouse and field-service counters. The dock ships with a power supply that accepts regional plug types, which simplifies deployment across multiple territories.

Connect the USB-R or RS232 cable to the host before inserting the terminal. The high-retention USB-R Type B port is client-only, so it does not support USB host devices such as keyboards or flash drives. The RS232 port uses a standard D-sub connector and supports serial data transfer for legacy applications. Route cables through the rear channel to keep the desk surface clear. The spare battery slot accepts standard and high-capacity Skorpio battery packs, and the dock charges the spare independently of the terminal.

Key Features

• Dual Charging Paths
  The cradle charges the mobile computer in the front slot and a spare battery in the rear bay simultaneously.

• High-Retention USB-R Type B Port

  • Client-only USB connection to the host PC
  • Retention clip holds the cable during repeated docking
  • Supports standard USB data transfer rates

• RS232 Serial Port
  A D-sub serial port supports legacy host systems and fixed-mount terminals.

• Desk Mount Base
  The weighted base with rubber feet stabilises the cradle during one-handed insertion.

• Regional Power Supply Included
  The package ships with a power adapter and interchangeable plugs for multiple regions.

• Skorpio X3 and X4 Compatibility
  The dock accepts both Skorpio X3 and Skorpio X4 mobile computer models.

Specifications

What’s in the Box

• Datalogic 94A150062 single slot desk mount dock

• Power supply with regional plugs

• USB cable

• Quick start documentation

Why Choose This Docking Cradle

• Dual charging paths keep a spare battery ready without a separate charger.

• The high-retention USB-R port resists accidental disconnection in busy scan stations.

• RS232 support extends the dock into legacy serial host environments.

• The weighted desk base allows one-handed docking and undocking.

• Regional plug options simplify multi-country rollouts.

• Skorpio X3 and X4 compatibility covers two generations of mobile computers.

• The compact 197 x 111 mm footprint fits a counter or packing bench.
