7 Pin Female Plug Plastic – 12V/24V Trailer Connector
Original price was: KSh 6,900.00.KSh 5,600.00Current price is: KSh 5,600.00. ex VAT
7 Pin Female Plug Plastic – 12V/24V Trailer Connector
| Connector Type | 7-pin female plug |
| Housing Material | Plastic (PA) |
| Contact Material | Brass |
| Number of Pins | 7 |
| Rated Voltage | 12 V DC / 24 V DC |
| Max Current per Pin | 10 A |
| Termination | Screw terminals |
| Cable Core Range | 1.5 mm² – 2.5 mm² |
| Cable Diameter Range | Up to 9.1 mm |
| Operating Temperature | -25 °C to +75 °C |
| Colour | Black |
| Standard | DIN/ISO 1724 N-type |
| Plug Length | 110 mm |
| Connector Diameter | 37 mm |
| Weight | 120 g |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Plastic Electrical Connector for Trailer and Vehicle Wiring
The 7 pin female plug provides a secure electrical interface for trailer lighting and auxiliary circuits on towing vehicles. It accepts standard 7-core cable and mates with the corresponding male socket on the vehicle harness. The plastic housing resists corrosion and simplifies plug removal during coupling and uncoupling.
Seven brass contacts carry lighting, indicator, brake, and auxiliary signals. The connector supports 12 V DC and 24 V DC systems with a maximum current rating of 10 A per pin. Screw terminals accept cable cores from 1.5 mm² to 2.5 mm² and suit field termination without specialised crimping tools.
A moulded plastic body insulates the contacts from moisture and road debris. The connector operates across a -25 °C to +75 °C temperature range and meets DIN/ISO 1724 N-type wiring conventions. Cable entry passes through a gland that accepts cable diameters up to 9.1 mm.
Key Features
Seven-Pin Configuration
Seven brass contacts map to lighting, brake, indicator, and auxiliary circuits for trailer wiring.Dual Voltage Support
The connector operates on 12 V DC and 24 V DC vehicle electrical systems.Screw Terminal Termination
Screw terminals accept 1.5 mm² to 2.5 mm² cable cores for field installation without crimping tools.Plastic Housing
A moulded plastic body insulates contacts and resists corrosion in outdoor environments.Gland Cable Entry
A screwed gland accepts cable diameters up to 9.1 mm and seals the cable entry point.Temperature Range
The connector operates from -25 °C to +75 °C across seasonal and climate variations.
Specifications
| Feature | Specification |
|---|---|
| Connector Type | 7-pin female plug |
| Housing Material | Plastic (PA) |
| Contact Material | Brass |
| Number of Pins | 7 |
| Rated Voltage | 12 V DC / 24 V DC |
| Max Current per Pin | 10 A |
| Termination | Screw terminals |
| Cable Core Range | 1.5 mm² – 2.5 mm² |
| Cable Diameter Range | Up to 9.1 mm |
| Operating Temperature | -25 °C to +75 °C |
| Colour | Black |
| Standard | DIN/ISO 1724 N-type |
| Plug Length | 110 mm |
| Connector Diameter | 37 mm |
| Weight | 120 g |
What’s in the Box
7-pin female plug
Screw terminal set
Cable gland
Instruction leaflet
Why Choose This Connector
Seven brass contacts handle trailer lighting and auxiliary circuits in one connection.
Screw terminals simplify field repairs and cable replacement without crimping equipment.
Plastic construction resists rust and corrosion on exposed vehicle wiring.
Dual voltage compatibility covers 12 V and 24 V vehicle electrical systems.
The DIN/ISO 1724 N-type layout matches common European trailer wiring conventions.
