Vention DAEBQ VGA Cable 20m 3+6 Male to Male Ferrite Cores 1080p Black
Original price was: KSh 2,700.00.KSh 2,200.00Current price is: KSh 2,200.00. ex VAT
Vention DAEBQ VGA Cable 20m 3+6 Male to Male Ferrite Cores 1080p Black
| Model | DAEBQ |
| Connector | VGA DE-15 male to VGA DE-15 male |
| Length | 20 m |
| Conductors | 3+6 configuration, 28 AWG oxygen-free copper |
| Shielding | Double shielded with dual ferrite cores |
| Plating | Gold-plated contacts |
| Jacket | PVC, 7.5 mm outer diameter, black |
| Resolution | Up to 1920 x 1080 at 60 Hz |
| Warranty | 1 year |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
Long-Run Analog Video Interconnect
The Vention DAEBQ is a 20-metre VGA cable with a 3+6 conductor configuration and dual ferrite cores at each end. Vention builds it for long analog video runs between a source and a display in large rooms. The black PVC jacket measures 7.5 mm in outer diameter and carries 28 AWG oxygen-free copper conductors.
The 3+6 layout dedicates three coaxial lines to the red, green and blue video signals, while six auxiliary conductors carry horizontal sync, vertical sync and DDC data. This separation limits cross-talk between the colour channels. Gold-plated DE-15 male connectors on both ends resist corrosion across repeated mating cycles.
Double shielding combines an aluminium foil wrap with a braided metal layer. The ferrite cores clamp onto the cable near each connector and suppress high-frequency noise picked up over the 20 m run. The assembly supports 1920 x 1080 at 60 Hz and weighs roughly 1.43 kg in total. The PVC jacket operates from -10°C to 70°C and stores from -20°C to 80°C.
Key Features
20-Metre Run for Large Rooms
The 20 m length reaches projectors, monitors and displays in auditoriums and conference halls without an extender.3+6 Conductor Architecture
- Three coaxial lines carry the RGB video channels
- Six auxiliary conductors handle sync and DDC signalling
- The split layout reduces cross-talk between colour channels
Dual Ferrite Cores
Moulded ferrite beads at each connector suppress electromagnetic and radio-frequency interference over the long cable span.Double-Shielded Construction
Aluminium foil and a metal braid wrap the conductor bundle to limit EMI ingress from nearby power cabling.Oxygen-Free Copper Conductors
28 AWG oxygen-free copper carries the analog signal with lower resistance and less attenuation than copper-clad aluminium alternatives.Gold-Plated DE-15 Connectors
Gold plating on the 15-pin male contacts limits oxidation in humid rooms and across repeated reconnect cycles.1080p 60 Hz Support
The cable carries 1920 x 1080 at 60 Hz for Full HD projectors and legacy monitors.Plug-and-Play Compatibility
The assembly needs no drivers and works with any VGA-enabled desktop, laptop, projector or display.
Specifications
| Feature | Specification |
|---|---|
| Model | DAEBQ |
| Connector Type | VGA (DE-15) male to VGA (DE-15) male |
| Length | 20 m |
| Conductor Configuration | 3 coaxial plus 6 auxiliary (3+6) |
| Conductor Gauge | 28 AWG |
| Conductor Material | Oxygen-free copper |
| Contact Plating | Gold |
| Shielding | Double shielded (foil plus braid) |
| Interference Control | Dual ferrite cores |
| Outer Jacket | PVC |
| Cable Diameter | 7.5 mm |
| Colour | Black |
| Maximum Resolution | 1920 x 1080 at 60 Hz |
| Signal Type | Analog video |
| Operating Temperature | -10°C to 70°C |
| Storage Temperature | -20°C to 80°C |
| Compliance | RoHS |
| Gross Weight | 1.4284 kg |
| Warranty | 1 year |
What’s in the Box
20 m VGA cable
Quick start documentation
Why Choose the DAEBQ
The 20 m span removes the need for a signal extender or repeater in large halls and lecture theatres.
Ferrite cores and double shielding hold the analog signal steady near fluorescent ballasts and power trunking.
The 3+6 conductor split keeps RGB channels isolated, which limits colour smearing on long runs.
Oxygen-free copper conductors reduce signal loss across the full 20 m length.
Gold-plated contacts and a moulded PVC jacket survive repeated setup and teardown in shared rooms.
