OEM DP7-6 6V 7Ah Sealed Lead Acid Battery

OEM DP7-6 Battery

The OEM DP7-6 6V Battery provides a stable direct current source for critical electronic infrastructure. This valve-regulated lead acid (VRLA) unit utilizes advanced absorbent glass mat (AGM) technology to immobilize the electrolyte. This design eliminates the risk of acid leakage during transport or operation. The battery maintains a nominal 6V output with a rated capacity of 7Ah at a 20-hour discharge rate. It serves as a primary energy storage component for uninterruptible power supplies and security systems. The internal construction features high-purity lead plates to maximize chemical reaction efficiency. This ensures consistent performance during high-current discharge events.

Key Features

• AGM Recombination Technology
  Internal glass fiber mats trap the electrolyte to achieve a 99% gas recombination efficiency during normal operation.

• Maintenance-Free Construction
  The sealed system prevents electrolyte evaporation and removes the requirement for periodic water replenishment or gravity checks.

• Durable Housing

  • Constructed from high-impact ABS resin for physical protection.
  • UL94-HB flame retardant rating available for specific regulatory compliance.
  • Leak-proof design allows mounting in vertical or horizontal orientations.

• Low Self-Discharge Rates
  Lead-calcium alloy grids reduce internal resistance to maintain charge levels during extended storage periods.

Operational Parameters

The energy storage unit operates across a wide temperature spectrum. Discharge occurs reliably between -15°C and 50°C. Charging requires a constant voltage source to prevent grid corrosion. For float applications, maintain a voltage between 6.75V and 6.90V at 25°C. Cyclic applications require a higher charging voltage ranging from 7.20V to 7.50V. Current limitation is necessary during initial charging phases to prevent thermal runaway. Limit the initial current to 2.1A or less. The battery exhibits high recovery capabilities even after deep discharge cycles. However, users should avoid leaving the unit in a discharged state for prolonged durations.

Specifications

What’s in the Box

• 1 x OEM DP7-6 Sealed Lead Acid Battery

• Terminal Protectors (Pre-installed)

Why Choose OEM DP7-6 Battery

• High energy density ensures a compact footprint for space-constrained enclosures.

• Rugged internal plate design resists mechanical vibrations and shocks.

• The oxygen recombination cycle prevents the need for maintenance throughout the service life.

• Standard F1 terminals provide secure electrical connections for quick deployment.
