NETGEAR XSM4316PB-100NES M4300-16X POE+ SWITCH
Original price was: KSh 414,000.00.KSh 357,000.00Current price is: KSh 357,000.00.
NETGEAR XSM4316PB-100NES M4300-16X POE+ SWITCH
| Ports | 16 × 100M/1G/2.5G/5G/10GBASE-T PoE+ |
| PoE Budget | 500W (30W per port) |
| Switching Capacity | 320 Gbps |
| Layer | L3 Managed |
| Stacking | Yes (8 units) |
| Routing | OSPF, RIP, Static |
| Power Supply | 1 × APS600W Included |
| Form Factor | Half-Width 1U |
Shipping & Delivery
Fast delivery
Your order will be deliver to the specified address
15 - 45 minutes
From KES 300
Warranty 1 year
Free 30-Day returns
Description
NETGEAR XSM4316PB (M4300-16X) 16-Port 10GBASE-T PoE+ Managed Switch
The NETGEAR XSM4316PB (M4300-16X) 16-Port 10GBASE-T PoE+ Managed Switch is a high-performance Layer 3 fully managed switch engineered for next-generation enterprise, campus, and data center networks. Featuring 16 multi-gigabit 100M/1G/2.5G/5G/10GBASE-T PoE+ ports, the switch delivers exceptional throughput with a non-blocking 320 Gbps fabric and advanced routing, stacking, and automation capabilities.
Key Features
-
16 × Multi-Gig 100M/1G/2.5G/5G/10GBASE-T Ports with PoE+
Delivers up to 30W per port with a total 500W PoE budget, ideal for Wi-Fi 6/6E APs, IP cameras, and VoIP infrastructure. -
High-Performance Switching Fabric
Provides 320 Gbps non-blocking throughput and 238 Mpps forwarding rate. -
Advanced L3 Routing Capability
Supports OSPF, OSPFv3, RIP, RIP-1/2, static routing, DHCP services, and VRRP. -
Non-Stop Forwarding Stacking Architecture
Up to 8 units can be stacked with seamless failover and distributed management. -
Flexible Half-Width Rack Design
Two units fit side-by-side into 1U rack space for redundant or high-density deployments. -
Comprehensive Security Framework
ACLs, DHCP snooping, BPDU protection, MAC authentication, guest VLANs, IGMP snooping. -
Out-of-Band Management
Includes a dedicated 1G OOB management port, RJ45 console, Mini-USB console, and USB storage. -
Low Noise Operation
Extremely quiet design with only 35–36 dB acoustic output depending on PSU.
Specifications
| Feature | Specification |
|---|---|
| Model | NETGEAR XSM4316PB-100NES (M4300-16X PoE+) |
| Switch Type | Fully Managed |
| Switching Layer | Layer 3 |
| Ports | 16 × 100M/1G/2.5G/5G/10GBASE-T RJ45 with PoE+ |
| Console Ports | RJ-45, Mini-USB |
| USB Ports | 1 × USB 2.0 |
| Management Port | 1 × 1G OOB Ethernet |
| SFP/SFP+ Slots | None |
| PoE Support | PoE+ (802.3at) |
| PoE Per-Port Power | 30W |
| Total PoE Budget | 500W |
| Switching Capacity | 320 Gbps |
| Forwarding Rate | 238 Mpps |
| MAC Address Table | 16,000 entries |
| Number of VLANs | 4093 |
| Jumbo Frame Support | 9000 bytes |
| Routing Protocols | OSPF, OSPFv3, RIP, RIP-1/2, Static |
| Stacking Support | Yes, up to 8 units |
| MTBF | 690,301 hours |
| Internal Memory | 1024 MB |
| Processor | 800 MHz CPU |
| Airflow | Front-to-Back |
| Acoustic Noise | 35–36 dB |
| PSU Included | 1 × APS600W modular PSU |
| Max Power Consumption | 610W |
| Form Factor | 1U Half-Width Rackmount |
| Dimensions | 212 × 345 × 44 mm |
| Weight | 3.22 kg |
| Operating Standards | IEEE 802.1D/Q/ab/p/s/v/w, 802.3/3ad/3af/3at/3az/3bz |
| HS Code | 85176990 |
| Color | Black |
What’s in the Box
-
1 × NETGEAR XSM4316PB (M4300-16X) Managed Switch
-
1 × APS600W Modular Power Supply
-
Rack Mounting Kit (Single & dual half-width brackets)
-
Console Cables (RJ45 & Mini-USB)
-
Quick Start Guide & Documentation
Why Choose the NETGEAR XSM4316PB (M4300-16X)
-
Multi-gig 10G PoE+ ports ideal for Wi-Fi 6/6E access points
-
High-performance L3 core switching for enterprise networks
-
Non-stop forwarding stacking ensures continuous uptime
-
Half-width design enables flexible and redundant rack layouts
-
OOB management enhances control and secure remote monitoring
-
Quiet operation suitable for office, wiring closets, and server rooms
-
Future-proof multi-gig support for next-gen network upgrades
