MV238FHM-N62 23.8-Inch AIO Replacement Screen FHD 1920×1080 30-Pin LVDS Non-Touch
Original price was: KSh 29,500.00.KSh 24,000.00Current price is: KSh 24,000.00. ex VAT
MV238FHM-N62 23.8-Inch AIO Replacement Screen FHD 1920×1080 30-Pin LVDS Non-Touch
| Panel model | MV238FHM-N62 |
| Diagonal size | 23.8 inch |
| Resolution | 1920 x 1080 |
| Panel technology | ADS, IPS-type |
| Brightness | 250 cd/m² |
| Contrast ratio | 1000:1 |
| Viewing angles | 89/89/89/89 |
| Interface | 30-pin LVDS |
| Input voltage | 5.0 V typical |
| Outline dimensions | 535 x 313 x 12 mm |
| Touch layer | None |
| Compatible chassis | Select 23.8-inch HP and Dell AIO desktops |
Same day Delivery
Delivery
We deliver to the address you provide. Nairobi is often same-day on business days.
Across the country
Delivery outside CBD starts from KES 300
Warranty 1 year
72-hour (3-day) returns
Description
23.8-Inch All-in-One Replacement Panel
The MV238FHM-N62 replacement screen is a 23.8-inch Full HD panel for all-in-one desktop repair. It carries a 1920 x 1080 native resolution on an ADS wide-viewing active area. A 30-pin LVDS connector matches the internal display cable in many HP and Dell AIO chassis.
The panel measures 535 x 313 x 12 mm overall with a 527.04 x 296.46 mm active area. A 250 cd/m² backlight pairs with a 1000:1 contrast ratio and 72% NTSC colour gamut. The matte anti-glare surface carries 25% haze against window reflections.
WLED backlighting runs on a 20S4P bar layout rated for 30,000 hours. Input voltage sits at 5.0 V typical, and the panel relies on the host mainboard for backlight drive. Operating range spans 0 °C to 50 °C, which covers indoor office conditions.
Key Features
1920 x 1080 ADS Panel
The 23.8-inch active area delivers roughly 92 pixels per inch at desk distance.30-Pin LVDS Interface
- Two-channel 8-bit LVDS carries the full 1080p signal
- 5.0 V typical input matches standard AIO board power
- No adapter required when the original cable matches
Matte Anti-Glare Surface
A 3H hard coat with 25% haze limits reflections from overhead lighting.89-Degree Viewing Angles
Colour and contrast hold on all four axes for off-centre viewing.Non-Touch Construction
The panel restores image output only and does not add a touch layer.Slim 12 mm Profile
The depth fits standard 23.8-inch AIO cavities without mounting changes.
Specifications
| Feature | Specification |
|---|---|
| Panel model | MV238FHM-N62 |
| Diagonal size | 23.8 inch |
| Native resolution | 1920 x 1080 |
| Panel technology | ADS, IPS-type |
| Pixel density | Approximately 92 PPI |
| Refresh rate | 60 Hz |
| Brightness | 250 cd/m² typical |
| Contrast ratio | 1000:1 typical |
| Viewing angles | 89/89/89/89 typical |
| Colour depth | 16.7 million colours, 8-bit |
| Colour gamut | 72% NTSC |
| Response time | 14 ms grey to grey |
| Surface treatment | Matte anti-glare, 25% haze, 3H hardness |
| Interface | LVDS, 30 pin, 2-channel 8-bit |
| Input voltage | 5.0 V typical |
| Backlight | WLED, 20S4P bar, 30,000-hour rating |
| Outline dimensions | 535 x 313 x 12 mm |
| Active area | 527.04 x 296.46 mm |
| Panel weight | Approximately 2.2 kg |
| Bezel design | 3-side borderless |
| Touch layer | None |
| Operating temperature | 0 °C to 50 °C |
| Storage temperature | -20 °C to 60 °C |
| Compatible chassis | Select 23.8-inch HP and Dell AIO desktops |
| Cross-reference codes | MV238FHM-N60, MV238FHM-N61, M26781-001, N08197-001, DP/N 020H2C |
What’s in the Box
MV238FHM-N62 23.8-inch Full HD replacement panel
Protective packaging
Why Choose the MV238FHM-N62 Panel
A single panel swap returns a working AIO to service instead of replacing the whole desktop.
The 30-pin LVDS layout matches common HP EliteOne and Dell OptiPlex AIO harnesses.
ADS technology holds colour across wide angles for shared reception and classroom screens.
The matte finish cuts glare from windows and overhead office lighting.
A 12 mm depth fits slim-bezel chassis without spacing adapters.
Cross-reference codes let technicians confirm fitment against the original label before ordering.
